TPA Method was Used to Analyze the Texture and Split of F1 Fruit of Jujube Hybrid

doi:10.6048/j.issn.1001-4330.2023.03.011

Xinjiang Agricultural Sciences ›› 2023, Vol. 60 ›› Issue (3): 608-615.DOI: 10.6048/j.issn.1001-4330.2023.03.011

• Horticultural Special Local Products·Physiology and Biochemistry • Previous Articles Next Articles

TPA Method was Used to Analyze the Texture and Split of F₁ Fruit of Jujube Hybrid

YANG ZHi¹^,²(), DONG Mengyi¹^,², WANG Zhenlei¹^,², YAN Fenfen¹^,², WU Cuiyun¹^,², WANG Jiurui¹^,³, LIU Mengjun¹^,³(), LIN Minjuan¹^,²()

1. The National and Local Joint Engineering Laboratory of High Efficiency and Superior-Quality Cultivation and Fruit Deep Processing Technology of Characteristic Fruit Trees in Southern Xinjiang/College of Plant Science, Tarim University, Alar Xinjiang, 843300, China
2. Key Laboratory of Protection and Utilization of Biological Resources in Tarim Basin, Xinjiang Production & Construction Corps, Tarim University, Alar Xinjiang 843300,China
3. Hebei Agricultural Vniversity Chinese Date Research Center,Baoding Hebei 071001,China

Received:2022-08-05 Online:2023-03-20 Published:2023-04-18
Correspondence author: LIN Minjuan (1979-), female, professor, research interest: fruit germplasm resources and genetic breeding,(E-mail)lmjzky@163.com;
Liu Mengjun (1965-), male, professor, doctoral supervisor, research interest: dried fruit germplasm resources and molecular breeding,(E-mail)lmj1234567@aliyun.com
Supported by:
The Science and Technology Innovation Leading Talents Program of the XPCC(2018CB032);Science and Technology Support Program for Key Industries in Southern Xinjiang(2017DB006);Innovation and Entrepreneurship Platform and Base Construction Project(2019CB001);National Key Research and Development Program of the 13th Five-Year Plan(2019YFD1001605)

基于TPA法枣酸枣杂交F₁果实质地与裂果对比分析

杨植¹^,²(), 董梦怡¹^,², 王振磊¹^,², 闫芬芬¹^,², 吴翠云¹^,², 王玖瑞¹^,³, 刘孟军¹^,³(), 林敏娟¹^,²()

1.南疆特色果树高效优质栽培与深加工技术国家地方联合工程实验室/新疆生产建设兵团南疆特色果树生产工程实验室/塔里木大学植物科学学院,新疆阿拉尔 843300
2.新疆生产建设兵团塔里木盆地生物资源保护利用重点实验室,新疆阿拉尔 843300
3.河北农业大学中国枣研究中心,河北保定 071001

通讯作者: 林敏娟(1979-),女,河北人,教授,硕士生导师,研究方向为果树种质资源与遗传育种,(E-mail)lmjzky@163.com;
刘孟军(1965-),男,河北人,教授,博士生导师,研究方向为干果种质资源与分子育种,(E-mail)lmj1234567@aliyun.com
作者简介:杨植(1995-),男,陕西人,硕士研究生,研究方向为果树遗传育种,(E-mail)1256007929@qq.com
基金资助:
兵团中青年科技创新领军人才计划(2018CB032);南疆重点产业科技支撑计划(2017DB006);创新创业平台与基地建设项目(2019CB001);国家十三五重点研发项目(2019YFD1001605)

Abstract

Abstract:

【Objective】 To evaluate the texture diversity of F₁ hybrid fruit between jujube and jujube and reveal the relationship between different texture fruit and split fruit. 【Methods】 Correlation analysis, principal component analysis and cluster analysis were used to conduct TPA analysis on fruit of F1 generation and its parents of jujube male sterility JMS2 (Z.jujuba JMS2)× jujube Xing16 (Z.acidojujuba) and to compare Dehiscent fruit rate. By analyzing the stress curve, 7 fruit texture parameters including hardness, adhesion, cohesiveness, elasticity, breaking force, adhesiveness and chew ability were obtained. 【Results】 The results showed that the indexes of fruit texture were separated to different degrees, and the coefficient of variation was 17.79%-52.43%. Correlation analysis found that elasticity, rupture strength, adhesiveness and chewiness were extremely positively correlated, correlation coefficients were distributed between 0.33-0.94, and hardness, adhesiveness and chewiness had strong correlation with other indicators and cohesion were very negatively correlated with hardness, fracture force, and the adhesive. Using principal component analysis, the seven texture parameters were transformed into four principal components contributing to 96.47%, which were hardness factor, cohesion factor, adhesion factor and elastic factor. According to the four fruit essence landlord component cluster analysis, the hybrid group different fruit quality was divided into three groups, which were dense soft group, high elastic hard maternal group and median paternal group. Median paternal group is the largest among the three groups, accounting for 76.56% of the total.【Conclusion】 It is found that the group with high hardness, viscosity and elasticity parameters or high pulp cohesiveness has lower Dehiscent fruit rate.

Key words: jujube; F₁ group; character; principal component; clustering analysis

摘要：

【目的】评价枣和酸枣杂交F₁代果实质地多样性,分析不同质地果实与裂果的关系。【方法】采用相关性分析、主成分和聚类分析等方法,研究枣雄性不育JMS2(Z.jujuba)×酸枣邢16(Z.acidojujuba)的F₁代及其亲本果实,基于TPA分析并对比果实裂果率。运用应力曲线得出硬度、粘附性、内聚性、弹性、破裂力、胶粘性和咀嚼性7个果实质地参数。【结果】各果实质地指标均有不同程度的分离,变异系数分布17.79%~52.43%。弹性、破裂力、胶粘性和咀嚼性呈极显著正相关,相关性系数分布在0.33~0.94,硬度、胶粘性和咀嚼性与其他指标相关性较强,内聚性与硬度、破裂力呈极显著负相关,与粘附性呈显著性负相关,应用主成分分析,把7个质地参数,转化为累计贡献率为96.47%的4个主成分分别为硬度因子、内聚因子、粘附因子和弹性因子,杂交群体不同果实质地分成3个群体,分别为绵密软质群、高弹硬质母本群和中值父本群。中值父本群是3个类群中最大的,占总数的76.56%。【结论】硬度、胶粘性和弹性参数高或果肉内聚性高的类群裂果率更低。

关键词: 枣, F₁群体, 花性状, 主成分, 聚类分析

CLC Number:

S665.1

YANG ZHi, DONG Mengyi, WANG Zhenlei, YAN Fenfen, WU Cuiyun, WANG Jiurui, LIU Mengjun, LIN Minjuan. TPA Method was Used to Analyze the Texture and Split of F₁ Fruit of Jujube Hybrid[J]. Xinjiang Agricultural Sciences, 2023, 60(3): 608-615.

杨植, 董梦怡, 王振磊, 闫芬芬, 吴翠云, 王玖瑞, 刘孟军, 林敏娟. 基于TPA法枣酸枣杂交F₁果实质地与裂果对比分析[J]. 新疆农业科学, 2023, 60(3): 608-615.

Figures/Tables 9

References 33

[1]	Liu M, Wang J, Wang L, et al. The historical and current research progress on jujube-a superfruit for the future[J]. Horticulture Research, 2020, 7(1):119. DOI PMID
[2]	Roth M, Muranty H, Guardo M D, et al. Genomic prediction of fruit texture and training population optimization towards the application of genomic selection in apple[J]. Horticulture Research, 2020.
[3]	Seymour G B, Kenneth M, Eriksson E M, et al. Genetic identification and genomic organization of factors affecting fruit texture[J]. Journal of Experimental Botany, 2002,(377):2065-2071. DOI PMID
[4]	CN101297634. 一种基于雄性不育利用和胚培养的枣树高效杂交育种方法[P].
	CN101297634. An efficient hybrid breeding method of jujube trees based on male sterility utilization and embryo culture[P].
[5]	Bargel H, Neinhuis C. Tomato (Lycopersicon esculentum Mill.) fruit growth and ripening as related to the biomechanical properties of fruit skin and isolated cuticle[J]. Journal of Experimental Botany, 2005, 56(413).
[6]	潘好斌, 刘东, 邵青旭. 等. 不同品种薄皮甜瓜成熟期果实质地品质分析及综合评价[J]. 食品科学, 2019, 40(21):43-50.
	PAN Haobin, LIU Dong, SHAO Qingxu, et al. Analysis and Comprehensive Evaluation of Textural Quality of Ripe Fruits from Different Varieties of Oriental Melon (Cucumis melo var.makuwa Makino)[J]. Food Science, 2019, 40(21):35-42. DOI
[7]	López-Casado G, Matas A J, Domínguez E, et al. Biomechanics of isolated tomato (Solanum lycopersicum L.) fruit cuticles: the role of the cutin matrix and polysaccharides[J]. Journal of Experimental Botany, 2007, 58(14).
[8]	辛艳伟, 集贤, 刘和. 裂果性不同的枣品种果皮及果肉发育特点观察研究[J]. 中国农学通报, 2006,(11):253-257.
	XIN Yanwei, JI Xian, LIU He. Observation on the Characteristics of Pericarp and Flesh Development of Jujube Varieties with Different Fruit Crapping Characteristics[J]. Chinese Agricultural Science Bulletin, 2006,(11):253-257.
[9]	王建宇, 高秋玲, 张晶晶. 等. 枣裂果相关的基因筛选[J]. 分子植物育种, 2020,(10):1-24.
	WANG Jianyu, GAO Qiuling, ZHANG Jingjing, et al. Screening of genes related to fruit cracking in jujube[J]. Molecular Plant Breeding, 2020,(10):1-24.
[10]	王建宇. 枣裂果生理特征及转录组和蛋白组学分析[D]. 阿拉尔: 塔里木大学, 2020.
	WANG Jianyu. Physiological characteristics and transcriptome and proteomic analysis of fruit cracking of Zizyphus jujuba[D]. Alar: Tarim University, 2020.
[11]	齐秀东, 魏建梅, 李永红. 苹果果实质地软化过程中碳水化合物代谢及其关键酶基因表达的变化[J]. 园艺学报, 2015, 34(3):409-417.
	QI Xiudong, WEI Jianmei, LI Yonghong. Changes of carbohydrate metabolism and key enzyme gene expression during apple fruit texture softening[J]. Acta Horticulturae Sinica, 2015, 34(3): 409-417.
[12]	王建宇, 高秋玲, 王振磊. 等. 细胞代谢酶活性、碳水化合物及内源激素与枣裂果关系[J]. 新疆农业科学, 2020, 57(9):1689-1696. DOI
	WANG Jianyu, GAO Qiuling, WANG Zhenlei, et al. Relationship between cell metabolic enzyme activity, carbohydrate and endogenous hormone and fruit cracking of jujube[J]. Xinjiang Agricultural Sciences, 2020, 57(9): 1689-1696. DOI
[13]	张生智, 孙俊宝, 张未仲. 等. 甜樱桃不同品种内源激素含量与裂果相关性初步研究[J]. 中国农学通报, 2019, 35(19):64-67. DOI
	ZHANG Shengzhi, SUN Junbao, ZHANG Weizhong, et al. Preliminary study on the correlation between endogenous hormone content and fruit cracking in different sweet cherry varieties[J]. Chinese Agronomic Bulletin, 2019, 35(19): 64-67.
[14]	阳姝婷. 干旱胁迫对甜樱桃生理及果实品质的影响[D]. 成都: 四川农业大学, 2016.
	YANG Shuting. Effects of drought stress on physiology and fruit quality of sweet cherry[D]. Chengdu: Sichuan Agricultural University, 2016.
[15]	李娟, 陈杰忠, 胡又厘. 等. 水分胁迫对柑橘果皮细胞壁结构与代谢的影响[J]. 生态学报, 2008,(2):486-492.
	LI Juan, CHEN Jiezhong, HU Youli, et al. Effects of water stress on cell wall structure and metabolism of citrus peel[J]. Acta Ecologica Sinica, 2008,(2): 486-492.
[16]	张建光, 张健强, 吕明霞. 等. 相对湿度对高温胁迫下苹果果皮组织细胞膜功能的影响[J]. 华北农学报, 2005,(1):52-54.
	ZHANG Jianguang, ZHANG Jianqiang, LU Mingxia, et al. Effect of relative humidity on cell membrane function of apple peel tissue under high temperature stress[J]. Acta Agriculturae Sinica, 2005,(1): 52-54.
[17]	余杏. 汉中大樱桃裂果原因及预防措施[J]. 西北园艺(果树), 2020,(5):25-26.
	YU Xing. Causes and preventive measures of fruit cracking of Hanzhong cherry[J]. Northwest Horticulture (Fruit Tree), 2020,(5): 25-26.
[18]	刘佳, 邓家林, 田云. 等. 青脆李成熟期裂果主要原因及防治措施[J]. 现代农业科技, 2020,(5):83-85.
	LIU Jia, DENG Jialin, TIAN Yun, et al. Main causes and control measures of fruit cracking in ripening stage of Qingcui plum[J]. Modern Agricultural Science and Technology, 2020,(5): 83-85.
[19]	王金明. 大棚西红柿转色期裂果原因及对策[J]. 现代农村科技, 2020,(2):35.
	WANG Jinming. Causes and Countermeasures of fruit cracking during color changing period of greenhouse tomato[J]. Modern Rural Science and Technology, 2020,(2): 35.
[20]	朱玉, 范丽娜, 黄泽军. 等. 番茄耐裂果基因Cr3a的精细定位[J]. 园艺学报, 2020, 47(2):275-286.
	ZHU Yu, FAN Lina, HUANG Zejun, et al. Fine mapping of fruit cracking resistance gene cr3a in tomato[J]. Acta Horticulturae Sinica, 2020, 47(2): 275-286.
[21]	王秀刚, 胡翠平, 杨涛. 等. 百合品种粉美与多安娜杂交F₁代主要性状遗传分析[J]. 作物杂志, 2012, (4):90-94.
	WANG Xiugang, HU Cuiping, YANG Tao, et al. Genetic analysis of main characters in the first generation[J]. Crops, 2012,(4): 90-94.
[22]	胡国富, 李凤兰, 李成雁. 等. 不同熟期菜豆(油豆角)产量性状的相关性和主成分分析[J]. 中国蔬菜, 2010, 1(6):24-27.
	HU Guofu, LI Fenglan, LI Chengyan, et al. Correlation and principal component analysis of yield traits of Phaseolus vulgaris at different maturity[J]. Chinese Vegetable, 2010, 1(6):24-27.
[23]	郭淑华, 翟衡, 韩宁. 等. 葡萄种间杂交砧木育种F₁代植株耐碱性盐能力分析[J]. 植物学报, 2018, 53(1):51-58. DOI
	GUO Shuhua, ZHAI Heng, HAN Ning, et al. Analysis on alkali salt tolerance of F₁ generation of grape interspecific hybrid rootstock breeding[J]. Acta Botany Sinica, 2018, 53(1): 51-58.
[24]	付晴晴, 孙鲁龙, 翟衡. 等. 葡萄种间杂交砧木育种F₁代植株耐盐性分析[J]. 植物学报, 2017, 52(6):733-743. DOI
	FU Qingqing, SUN Lulong, ZHAI Heng, et al. Analysis on salt tolerance of F₁ generation of grape interspecific cross rootstock breeding[J]. Acta Botany Sinica, 2017, 52(6): 733-743.
[25]	刘大亮, 王进, 张艳敏. 等. 新疆野苹果F₁代果实性状的相关分析和主成分分析[J]. 山东农业科学, 2013,(8):19-24.
	LIU Daliang, WANG Jin, ZHANG Yanmin, et al. Correlation analysis and principal component analysis of fruit traits of Xinjiang wild apple F₁[J]. Shandong Agricultural Sciences, 2013,(8): 19-24.
[26]	边芯, 俞华先, 冯蔚. 等. 云南割手密及其血缘 F₁代材料抗旱相关性状的主成分分析[J]. 干旱地区农业研究, 2014, 32(3):56-61.
	BIAN Xin, YU Huaxian, FENG Wei, et al. Principal component analysis of drought resistance related traits of Yunnan chashoumi and its F₁ progenies[J]. Agricultural Research in Arid Areas, 2014, 32(3): 56-61.
[27]	何晓群. 多元统计分析[M]. 北京: 中国人民大学出版社, 2004.
	HE Xiaoqun. Multivariate statistical analysis[M]. Beijing: China Renmin University Press, 2004.
[28]	禄彩丽, 何秉宇, 马珊. 等. 环塔里木盆地骏枣质地品质及其与气象因子的关系[J]. 西北农林科技大学学报(自然科学版), 2021,(2):1-9.
	LU Caili, HE Bingyu, MA Shan, et al. Texture quality of Junzao around Tarim Basin and its relationship with meteorological factors[J]. Journal of Northwest University of Agriculture and Forestry Science and Technology (Natural Science Ed.), 2021,(2): 1-9.
[29]	杨植, 王振磊. 基于TPA法评价枣果实质地及聚类分析[J]. 新疆农业科学, 2019, 56(10):1860-1868. DOI
	YANG Zhi, WANG Zhenlei. Evaluation of jujube fruit quality based on TPA method and cluster analysis[J]. Xinjiang Agricultural Sciences, 2019, 56(10): 1860-1868. DOI
[30]	赵爱玲, 薛晓芳, 王永康. 等. 质构仪检测鲜枣果实质地品质的方法研究[J]. 果树学报, 2018, 35(5):631-641.
	ZHAO ailing, XUE Xiaofang, WANG Yongkang, et al. Study on the method of detecting the quality of fresh jujube fruit by texture analyzer[J]. Acta Pomology Sinica, 2018, 35(5): 631-641.
[31]	马庆华, 王贵禧, 梁丽松. 质构仪穿刺试验检测冬枣质地品质方法的建立[J]. 中国农业科学, 2011, 44(6):1210-1217.
	MA Qinghua, WANG Guixi, LIANG Lisong. Establishment of method for detecting texture quality of Dongzao by texture analyzer puncture test[J]. Chinese Agricultural Sciences, 2011, 44(6): 1210-1217.
[32]	Ma H, Huifang M, Yijun L, et al. yunOptimization of Test Conditions for TPA Texture Properties of Avocado Flesh[J]. IOP Conference Series: Earth and Environmental Science, 2020, 526(1).
[33]	Yang Y, Jun F, Yaoguang X, et al. Genome resequencing reveals the evolutionary history of peach fruit edibility.[J]. Nature Communications, 2018, 9(1):314-321. DOI

性状 Traits	最小值 Minimum	最大值 Maximum	极差 Range	均值 Mean	标准差 SD	变异系数 CV (%)	偏度 Skewness	峰度 Kurtosis
硬度 Hardness(N)	44.10	338.23	294.14	194.97	59.08	30.30	-0.10	-0.04
粘附性 Adhesiveness(N.mm)	0.08	0.99	0.91	0.23	0.12	52.43	2.33	10.46
内聚性 Cohesiveness(Ratio)	0.03	0.19	0.16	0.10	0.03	32.61	0.52	0.26
弹性 Springiness(mm)	4.03	11.41	7.38	7.59	1.35	17.79	0.05	-0.06
破裂力 Fractur ability(N)	0.00	310.40	310.40	152.14	79.16	52.03	-0.69	-0.13
胶粘性 Gumminess(N)	5.33	42.58	37.25	18.21	7.14	39.19	0.93	1.14
咀嚼性 Chewiness(mj)	29.14	436.89	407.76	142.43	72.87	51.16	1.34	2.52

性状 Traits	最小值 Minimum	最大值 Maximum	极差 Range	均值 Mean	标准差 SD	变异系数 CV (%)	偏度 Skewness	峰度 Kurtosis
硬度 Hardness(N)	44.10	338.23	294.14	194.97	59.08	30.30	-0.10	-0.04
粘附性 Adhesiveness(N.mm)	0.08	0.99	0.91	0.23	0.12	52.43	2.33	10.46
内聚性 Cohesiveness(Ratio)	0.03	0.19	0.16	0.10	0.03	32.61	0.52	0.26
弹性 Springiness(mm)	4.03	11.41	7.38	7.59	1.35	17.79	0.05	-0.06
破裂力 Fractur ability(N)	0.00	310.40	310.40	152.14	79.16	52.03	-0.69	-0.13
胶粘性 Gumminess(N)	5.33	42.58	37.25	18.21	7.14	39.19	0.93	1.14
咀嚼性 Chewiness(mj)	29.14	436.89	407.76	142.43	72.87	51.16	1.34	2.52

KMO 统计量 KMO statistics		0.570 08
巴特利特球形度检验 Bartlett's test for sphericity	近似卡方	1 008.388
	自由度	21
	显著性	0.00

KMO 统计量 KMO statistics		0.570 08
巴特利特球形度检验 Bartlett's test for sphericity	近似卡方	1 008.388
	自由度	21
	显著性	0.00

成分 Ingredient	提取载荷平方和 Extract load square
成分 Ingredient	总计 Aggregate	方差百分比 Variancepercent	累积 Accumulation (%)
1	3.338 1	47.687 6	47.687 6
2	1.848 9	26.413 2	74.100 8
3	0.898 4	12.834	86.934 8
4	0.667 5	9.535 9	96.470 7
5	0.200 3	2.862	99.332 7
6	0.035 7	0.510 6	99.843 3
7	0.011	0.156 7	100
