Effects of chlorine dioxide fumigation treatments on the storage of fresh walnuts

doi:10.6048/j.issn.1001-4330.2023.08.015

Xinjiang Agricultural Sciences ›› 2023, Vol. 60 ›› Issue (8): 1940-1949.DOI: 10.6048/j.issn.1001-4330.2023.08.015

• Horticultural Special Local Products · Agricultural Product Processing Engineering • Previous Articles Next Articles

Effects of chlorine dioxide fumigation treatments on the storage of fresh walnuts

WANG Ping¹(), KONG Na², PAN Yan³, SUN Xiping¹, XU Bin³, ZHANG Ting³()

1. College of Food and Pharmaceutical Sciences, Xinjiang Agricultural University, Urumqi 830052, China
2. Science and Technology of the Project of Service center of Xinjiang, Urumqi 830000, China
3. Research Institute of Farm Products Storage and Processing, Xinjiang Academy of Agricultural Sciences/Research Center of Main Agricultural Products Processing Engineering in Xinjiang/Key laboratory of Agricultural Products Processing and Preservation Xinjiang, Urumqi 830091, China

Received:2022-12-01 Online:2023-08-20 Published:2023-08-14
Correspondence author: ZHANG Ting(1980-),Femail,Research Fellow,Doctor,Research Fields:Storage and processing of agricultural products(E-mail)zhangtingkikie@163.com
Supported by:
National Nature Fund project"Study on the action mechanism of high CO2 treatments on inducingarbutin to control the postharvest browning of green light walnut(32260411);Science and Technology Assisting Xinjiang Project "Introduction and Demonstration of Modified Atmosphere Packaging (MAP) Fresh Storage Technology for Green Walnuts"(2019E0271)

ClO₂熏蒸处理对湿鲜核桃贮藏效果的影响

王苹¹(), 孔娜², 潘俨³, 孙席平¹, 徐斌³, 张婷³()

1.新疆农业大学食品科学与药学学院,乌鲁木齐 830052
2.新疆维吾尔自治区科技项目服务中心,乌鲁木齐 830000
3.新疆农业科学院农产品贮藏加工研究所/新疆主要农副产品精深加工工程技术研究中心/新疆农产品加工与保鲜重点实验室,乌鲁木齐 830091

通讯作者: 张婷(1980-),女,研究员,博士,研究方向为农产品贮运与加工(E-mail)zhangtingkikie@163.com
作者简介:王苹(1997-),女,硕士研究生,研究方向为农产品贮运与加工,(E-mail)1346521052@qq.com
基金资助:
国家自然科学基金项目“高CO2处理诱导薄皮核桃青皮熊果苷调控其采后褐变的作用机制研究”(32260411);新疆维吾尔自治区科技支疆项目“青皮核桃气调包装(MAP)鲜贮技术的引进与示范”(2019E0271)

Abstract

Abstract:

【Objective】 This project aims to carry out chlorine dioxide treatment experiments to regulate the effect of its low-temperature storage period in order to screen the appropriate treatment concentration.【Methods】 The main cultivar Wen 185 wet walnut in southern Xinjiang was taken as the test material, after fumigation with four concentrations of chlorine dioxide (ClO₂), 0(CK), 50, 100, and 150 mg/L, they were placed under (0±1)℃, RH 75%~80% condition and the mold rate of its seed shell were regularly counted, and the quality of physical and chemical indicators related to its seed kernels determined to analyze the effects of different concentrations of ClO₂ fumigation on its storage effect.【Results】 The results show that compared with the control CK, ClO₂ fumigation could inhibit the occurrence of mold on the surface of walnut nuts significantly and reduce the browning index of their seed coat, maintain walnut freshness and good nucleolar organoleptic quality with low acid valence and chlorine dioxide residuals, among which, the 100 and 150 mg/L ClO₂ treatments could delay the occurrence of wet-fresh walnut seed hull mold by 7 days, and the mildew rate was reduced by 10.67% and 7.33%, respectively compared with the control group.【Conclusion】 Comprehensive analysis show that the 100 mg/L ClO₂ treatment has the best effect.When stored for 49 days, the seed shell mold rate is 26.67%, the seed coat browned index was 18.89, and the rate of intact fruit was 86.67%.This result can provide theoretical reference and scientific basis for the application and promotion of practical technology for the storage, transportation and preservation of wet-fresh walnuts in production.

Key words: wet-fresh walnuts; ClO₂; shell mildew; kernel quality; preservation effect

摘要：

【目的】研究二氧化氯(ClO₂)处理对湿鲜核桃低温贮藏期间效果影响,筛选适宜的处理浓度,为生产中湿鲜核桃贮运保鲜实用技术的应用推广提供理论参考。【方法】以新疆主栽核桃品种温185湿鲜核桃为试材,采用0(CK)、50、100和150 mg/L四个浓度ClO₂熏蒸处理后,置于(0±1)℃、相对湿度(RH)75%~80%条件下,定期统计其种壳霉变率,测定种仁相关的品质和理化指标,分析不同浓度ClO₂熏蒸处理对湿鲜核桃贮藏效果的影响。【结果】与对照CK相比,ClO₂熏蒸处理可显著抑制核桃坚果表面霉菌发生,降低其种皮褐变指数,维持核桃新鲜度和较好的核仁感官品质,且酸价和ClO₂残留含量维持在较低水平,其中100和150 mg/L ClO₂处理可使湿鲜核桃种壳霉变发生时间推迟7 d,霉变率较对照组分别降低10.67%和7.33%。【结论】100 mg/L ClO₂熏蒸处理效果最好,贮藏49 d时,种壳霉变率为26.67%,种皮褐变指数为18.89,好果率达到86.67%。

关键词: 湿鲜核桃, 二氧化氯, 种壳霉变, 种仁品质, 保鲜效果

CLC Number:

S664.1

WANG Ping, KONG Na, PAN Yan, SUN Xiping, XU Bin, ZHANG Ting. Effects of chlorine dioxide fumigation treatments on the storage of fresh walnuts[J]. Xinjiang Agricultural Sciences, 2023, 60(8): 1940-1949.

王苹, 孔娜, 潘俨, 孙席平, 徐斌, 张婷. ClO₂熏蒸处理对湿鲜核桃贮藏效果的影响[J]. 新疆农业科学, 2023, 60(8): 1940-1949.

Figures/Tables 9

References 30

[1]	新疆维吾尔自治区统计局,国家统计局新疆调查总队. 新疆统计年鉴[J]. 北京:中国统计出版社, 2020.
	Xinjiang Uygur Autonomous Region Bureau of Statistics, Xinjiang Investigation Corps of the National Bureau of Statistics. Xinjiang Statistical Yearbook[J]. Beijing: China Statistics Press, 2020.
[2]	颉敏华, 陈柏, 吴小华, 等. 鲜核桃保鲜研究现状及思路调整建议[J]. 甘肃农业科技, 2020,(4):68-71.
	XIE Minhua, CHEN Bai, WU Xiaohua, et al. Research status and suggestions on fresh walnut preservation[J]. Gansu Agricultural Science and Technology, 2020,(4):68-71.
[3]	Weaver-Meyers P L, Stolt W A, Kowaleski B, et al. Controlling Mold on Library Materials with Chlorine Dioxide: an Eight year Case Study[J]. Journal of Academic Librarianship, 1998, 24(6):455-458. DOI URL
[4]	Smith D J, Ernst W, Herges G R. Chloroxyanion Residues in Cantaloupe and Tomatoes after Chlorine Dioxide Gas Sanitation[J]. Journal of Agricultural & Food Chemistry, 2015, 63(43):9640-9645.
[5]	Kaur S, Smith D J, Morgan M T. Chloroxyanion Residue Quantification in Cantaloupes Treated with Chlorine Dioxide Gas[J]. Journal of Food Protection, 2015, 78(9):1708-1718. DOI PMID
[6]	陈柏, 颉敏华, 吴小华, 等. 5种保鲜剂对低温贮藏去青皮核桃感官品质的影响[J]. 甘肃农业科技, 2018,(6):40-44.
	CHEN Bai, XIE Minhua, WU Xiaohua, et al. Effects of 5 preservatives on sensory quality during cold storage of peeled green walnut fruit[J]. Gansu Agricultural Science and Technology, 2018,(6):40-44.
[7]	Bang J, Kim H, Kim H, et al. Combined Effects of Chlorine Dioxide, Drying, and Dry Heat Treatments in Inactivating Microorganisms on Radish Seeds[J]. Food Microbiology, 2010, 28(1):114-118. DOI URL
[8]	Sadeghi K, Kasi G, Ketsuk P, et al. A Polymeric Chlorine Dioxide Self-releasing Sheet to Prolong Postharvest Life of Cherry Tomatoes[J]. Postharvest Biology and Technology, 2020, 161(C):221-228.
[9]	刘云飞, 纪海鹏, 陈存坤, 等. 二氧化氯对香梨贮藏后期品质保持效果的研究[J]. 包装工程, 2020, 41(5):1-7.
	LIU Yunfei, JI Haipeng, CHEN Cunkun, et al. Effect of chlorine dioxide Treatment on quality maintenance of korlapears in later storage period[J]. Packaging Engineering, 2020, 41(5):1-7.
[10]	徐呈祥, 郑福庆, 马艳萍, 等. 二氧化氯处理对贡柑采后贮藏品质的影响[J]. 食品与发酵工业, 2020, 46(3):201-206.
	XU Chengxiang, ZHENG Fuqing, MA Yanping, et al. Effect of chlorine dioxideon thequality of gongganmandar in fruits during postharvest storage[J]. Food and Fermentation Industry, 2020, 46(3):201-206.
[11]	潘莉, 李勇鹏, 宁德鲁, 等. 不同保鲜方法对核桃青皮感官及核桃仁可溶性蛋白含量的影响[J]. 中国油脂, 2021, 46(9):103-107.
	PAN Li, LI Yongpeng, NING Delu, et al. Effects of different preservation methods on the sensory and soluble protein content of green walnut[J]. Chinese Oils and Fats, 2021, 46(9):103-107.
[12]	袁德保, 刘兴华, 马艳萍, 等. 鲜食核桃贮藏中脂肪酶活性及油脂酸价变化[J]. 食品研究与开发, 2006,(11):79-81.
	YUAN Debao, LIU Xinghua, MA Yanping, et al. Changes of lipase activity and the acid value of oil in walnuts during storage[J]. Food Research and Development, 2006,(11):79-81.
[13]	黄凯, 袁德保, 韩忠. 鲜食核桃贮藏中生理生化变化的研究[J]. 安徽农业科学, 2008,(23):9858-9860,9960.
	HUANG Kai, YUAN Debao, HAN Zhong. Study on physiological and biochemical changes during the storage of fresh walnuts[J]. Anhui Agricultural Sciences, 2008,(23):9858-9860, 9960.
[14]	Geng Yy, Li Xu, Bao-Jun Ma, et al. The Quality and Physiological Changes in Different Kind Fresh Walnuts During Refrigeration[J]. Food Science and Technology, 2013,(3):49-54.
[15]	黄凯, 袁德保, 韩忠. 鲜食核桃贮藏中腐烂病原菌分离、鉴定及体外抑菌研究[J]. 食品工业科技, 2009, 30(1):150-152.
	HUANG Kai, YUAN Debao, HAN Zhong. Isolation, identification and antimicrobial effect in vitro of causative pathogen from mouldy fresh walnut during storage[J]. Technology for the Food Industry, 2009, 30(1):150-152.
[16]	李盼. 气调及保鲜剂处理对湿鲜核桃品质影响与生理机制研究[D]. 杨凌: 西北农林科技大学, 2018.
	LI Pan. Effect of controlled atmosphere and antistalingre agents’ treatments on quality and physiological mechanism of fresh walnuts[D]. Yangling: Northwest A&F University, 2018.
[17]	Yanping M, Pan L, Christtopher B, et al. Chlorine Dioxide and Sodium Diacetate Treatments in Controlled Atmospheres Retard Mold Incidence and Maintain Quality of Fresh Walnuts During Cold Storage[J]. Postharvest Biology and Technology, 2020, 161(C):2-6.
[18]	冯文煜, 蒋柳庆, 马惠玲, 等. 不同厚度PE膜包装对核桃果实采后生理与鲜贮的效应[J]. 食品科学, 2013, 34(18):295-300. DOI
	FENG Wenyu, JIANG Liuqing, MA Huiling, et al. Effects of modified atmosphere packaging with different thicknesses of PE filmon postharvest physiology and preservation of green walnut fruit[J]. Food Science, 2013, 34(18):295-300. DOI
[19]	Mexis S, Badeka A, Riganakos K, et al. Effect of Packaging and Storage Conditions on Quality of Shelled Walnuts[J]. Food Control, 2008, 20(8):743-751,181. DOI URL
[20]	王进, 蒋柳庆, 马惠玲, 等. ClO₂和1-MCP对青皮核桃二步贮藏的效应[J]. 中国食品学报, 2015, 15(3):137-145.
	WANG Jin, JIANG Liuqing, MA Huiling. et al. Effects of ClO₂ and 1-MCP on preservation of green fruit and peeled walnut in two-step storage[J]. Chinese Journal of Food Science, 2015, 15(3):137-145.
[21]	Jeng D K, Woodworth A G. Chlorine Dioxide Gas Sterilization Under Square-wave Conditions[J]. Applied and Environmental Microbiology, 1990, 56(2):514-519. DOI PMID
[22]	布妈热娅木·艾山, 潘俨, 徐斌, 等. 采收成熟度对青皮核桃鲜贮效果的影响[J]. 食品工业科技, 2020, 41(20): 273-278.
	BU Mareyamu Aishan, PAN Yan, XU Bin, et al. Effect of harvest maturity on preservation of green walnuts fruits[J]. Technology for the Food Industry, 2020, 41(20):273-278.
[23]	Christopoulos M V, Tsantili E. Storage of Fresh Walnuts (juglans Regia L.)-low Temperature and Phenolic Compounds[J]. Postharvest Biology and Technology, 2012, 73:80-88. DOI URL
[24]	耿阳阳, 徐俐, 马宝军, 等. 不同品种鲜食核桃冷藏期间品质及生理变化[J]. 食品科技, 2013, 38(3):49-54.
	GENG Yangyang, XU Li, MA Baojun, et al. Different varieties of fresh walnuts during refrigeration and physiological changes[J]. Food Technology, 2013, 38(3):49-54.
[25]	韩强, 郜海燕, 陈杭君, 等. ClO₂处理和包装方法对鲜核桃仁贮藏品质的影响[J]. 中国食品学报, 2017, 17(5): 130-137.
	HAN Qiang, GAO Haiyan, CHEN Hangjun, et al. Effect of ClO₂ treatment and packing methods on storage qualityof fresh walnut Kernel[J]. Chinese Journal of Food Science, 2017, 17(5):130-137.
[26]	Vanhanen L P, Savage G P. The Use of Peroxide Value as a Measure of Quality for Walnut Flour Stored at Five Different Temperatures Using Three Different Types of Packaging[J]. Food Chemistry, 2006, 99(1):64-69. DOI URL
[27]	张晓煜. 二氧化氯对细菌杀灭机理的研究[D]. 武汉: 中国科学院研究生院(武汉病毒研究所), 2006.
	ZHANG Xiaoyu. Studies on bactericidal mechanism of chlorine dioxide[D]. Wuhan: Graduate School of Chinese Academy of Sciences (Wuhan Institute of Virology), 2006.
[28]	Sun X, Elizabeth B, Bai J. Applications of Gaseous Chlorine Dioxide on Postharvest Handling and Storage of Fruits and Vegetables-A Review[J]. Food Control, 2018, 95:54-59.
[29]	沈金玉, 黄家音, 李晓莉. 果蔬酶促褐变机理及其抑制方法研究进展[J]. 食品研究与开发, 2005,(6):150-156.
	SHEN Jinyu, HUANG Jiayin, LI Xiaoli, et al. Advances in research on mechanism ofenzymatic browning and inhibition methods for fruits and vegetables[J]. Food Research and Development, 2005,(6):150-156.
[30]	Chen Z, Zhu C, Zhang Y, et al. Effects of Aqueous Chlorine Dioxide Treatment on Enzymatic Browning and Shelf-life of Fresh-cut Asparagus Lettuce (lactuca Sativa L.)[J]. Postharvest Biology &Technology, 2010, 58(3): 232-238.

感官指标 Sensory quality	一级 Level 1	二级 Level 2	三级 Level 3	四级 Level 4	五级 Level 4
种皮颜色Seed coat color	浅亮黄色	暗黄色	暗褐色	褐色	黑褐色
种皮剥离难易程度 Difficulty of peeling off the seed coat	易(可轻易大片剥除)	中(可小片剥取, 有残留)	难(难以剥取, 有大量残留)	极难剥	不可剥
核仁色泽Nucleus color	白色	黄白色	黄色	黄褐色	黑褐色
香气Aroma	浓郁清香	清香	淡清香	微弱清香	无香气
风味Flavor	香脆味浓	脆而味不浓	较脆,鲜味淡	失脆,无异味	有微酸味和韧感

感官指标 Sensory quality	一级 Level 1	二级 Level 2	三级 Level 3	四级 Level 4	五级 Level 4
种皮颜色Seed coat color	浅亮黄色	暗黄色	暗褐色	褐色	黑褐色
种皮剥离难易程度 Difficulty of peeling off the seed coat	易(可轻易大片剥除)	中(可小片剥取, 有残留)	难(难以剥取, 有大量残留)	极难剥	不可剥
核仁色泽Nucleus color	白色	黄白色	黄色	黄褐色	黑褐色
香气Aroma	浓郁清香	清香	淡清香	微弱清香	无香气
风味Flavor	香脆味浓	脆而味不浓	较脆,鲜味淡	失脆,无异味	有微酸味和韧感

贮藏天数 Storage days(d)	ClO₂处理 ClO₂ treatment (mg/L)	种皮颜色 (级) Seed coat color (grade)	种皮剥离难易程度(级) Difficulty of peeling off the seed coat/ grade	核仁色泽(级) Nucleus color (grade)	香气(级) Aroma (grade)	风味(级) Flavor (grade)	综合加权平均级别(级) Weighted flat average level(grade)
0	CK	1	1	1	1	1	1
	50	1	1	1	1	1	1
	100	1	1	1	1	1	1
	150	1	1	1	1	1	1
7	CK	1.2	1.5	1	1	1.1	1.17
	50	1.1	1.4	1	1	1	1.10
	100	1.1	1.4	1	1.1	1	1.12
	150	1	1.4	1	1.1	1.1	1.13
14	CK	1.6	1.5	1.2	1.5	1.2	1.35
	50	1.3	1.4	1.1	1.3	1.2	1.25
	100	1.2	1.4	1.1	1.2	1.1	1.19
	150	1.2	1.4	1.1	1.2	1.2	1.23
21	CK	1.4	1.7	1.1	1.4	1.4	1.42
	50	1.3	1.5	1.1	1.4	1.4	1.36
	100	1.3	1.6	1.1	1.3	1.2	1.29
	150	1.3	1.5	1.1	1.4	1.3	1.32
28	CK	2	1.7	1.2	2.2	1.5	1.64
	50	1.5	1.7	1.2	1.9	1.6	1.58
	100	1.3	1.7	1.2	1.8	1.5	1.50
	150	1.5	1.8	1.3	1.6	1.5	1.54
35	CK	2.1	2	1.3	2.2	2.1	1.97
	50	1.7	2.1	1.2	2	1.8	1.78
	100	1.5	1.8	1.2	2	1.7	1.65
	150	1.6	1.9	1.2	2	1.8	1.72
42	CK	2.6	2.6	1.4	2.9	2.8	2.53
	50	2.4	2.5	1.3	2.7	2.5	2.33
	100	1.9	2.3	1.3	2.3	2.1	2.01
	150	2.1	2.4	1.3	2.5	2.3	2.16
49	CK	2.9	3.2	1.6	4	3.3	3.04
	50	2.5	3.1	1.3	3.3	2.8	2.64
	100	2.3	2.7	1.2	2.8	2.3	2.27
	150	2.5	3	1.3	3	2.5	2.47

贮藏天数 Storage days(d)	ClO₂处理 ClO₂ treatment (mg/L)	种皮颜色 (级) Seed coat color (grade)	种皮剥离难易程度(级) Difficulty of peeling off the seed coat/ grade	核仁色泽(级) Nucleus color (grade)	香气(级) Aroma (grade)	风味(级) Flavor (grade)	综合加权平均级别(级) Weighted flat average level(grade)
0	CK	1	1	1	1	1	1
	50	1	1	1	1	1	1
	100	1	1	1	1	1	1
	150	1	1	1	1	1	1
7	CK	1.2	1.5	1	1	1.1	1.17
	50	1.1	1.4	1	1	1	1.10
	100	1.1	1.4	1	1.1	1	1.12
	150	1	1.4	1	1.1	1.1	1.13
14	CK	1.6	1.5	1.2	1.5	1.2	1.35
	50	1.3	1.4	1.1	1.3	1.2	1.25
	100	1.2	1.4	1.1	1.2	1.1	1.19
	150	1.2	1.4	1.1	1.2	1.2	1.23
21	CK	1.4	1.7	1.1	1.4	1.4	1.42
	50	1.3	1.5	1.1	1.4	1.4	1.36
	100	1.3	1.6	1.1	1.3	1.2	1.29
	150	1.3	1.5	1.1	1.4	1.3	1.32
28	CK	2	1.7	1.2	2.2	1.5	1.64
	50	1.5	1.7	1.2	1.9	1.6	1.58
	100	1.3	1.7	1.2	1.8	1.5	1.50
	150	1.5	1.8	1.3	1.6	1.5	1.54
35	CK	2.1	2	1.3	2.2	2.1	1.97
	50	1.7	2.1	1.2	2	1.8	1.78
	100	1.5	1.8	1.2	2	1.7	1.65
	150	1.6	1.9	1.2	2	1.8	1.72
42	CK	2.6	2.6	1.4	2.9	2.8	2.53
	50	2.4	2.5	1.3	2.7	2.5	2.33
	100	1.9	2.3	1.3	2.3	2.1	2.01
	150	2.1	2.4	1.3	2.5	2.3	2.16
49	CK	2.9	3.2	1.6	4	3.3	3.04
	50	2.5	3.1	1.3	3.3	2.8	2.64
	100	2.3	2.7	1.2	2.8	2.3	2.27
	150	2.5	3	1.3	3	2.5	2.47
