Determination of Fiber Component Content in the Residual Branches of Fruit Trees in South Xinjiang Based on Near Infrared Spectroscopy

doi:10.6048/j.issn.1001-4330.2022.08.024

Abstract

Abstract:

【Objective】 The detection of fiber components in fruit tree stumps generally has the problems of time-consuming, complicated operation and high test cost. The research uses near-infrared spectroscopy technology combined with chemometrics to quickly detect the content of cellulose, hemicellulose and lignin in the stumps of fruit trees in southern Xinjiang. 【Method】 Taking 150 samples of fruit tree stumps collected from various parts of southern Xinjiang as the research object, using near-infrared spectroscopy technology combined with partial least squares（PLS）, Using different pre-processing and characteristic waveband screening methods to optimize the prediction model of the content of each fiber component. 【Result】 The three fiber component near-infrared detection models established by the SG convolution smoothing method preprocessing combined with the competitive adaptive weight sampling method（CARS） optimized feature band have the best effect, and the correlation coefficients r are 0.950,3, 0.948,7 and 0.937,1, respectively. The coefficients of determination R² are 0.900,8, 0.896,5, and 0.875,1, the corrected standard deviations RMSEC were 0.007,0, 0.005,4, and 0.005,1, and the predicted standard deviations RMSEP were 0.011,8, 0.008,9, and 0.008,8, respectively. 【Conclusion】 The use of near-infrared spectroscopy technology can achieve rapid quantitative detection of the three components of cellulose, hemicellulose and lignin in fruit tree stumps in South Xinjiang.

Key words: near infrared spectroscopy; fruit tree stumps; quantitative analysis; cellulose; hemicellulose; lignin

摘要：

【目的】研究运用近红外光谱技术结合化学计量学实现快速检测新疆南疆果树残枝中纤维素、半纤维素和木质素含量。【方法】以150个从新疆南疆各地采集的果树残枝样本为材料,利用近红外光谱技术结合偏最小二乘法（PLS）,采用不同的预处理和特征波段筛选方法优化各纤维组分含量的预测模型。【结果】SG卷积平滑法预处理结合竞争性自适应权重取样法（CARS）优选特征波段建立的3种纤维组分近红外检测模型效果最优,相关系数r分别为0.950 3、0.948 7和0.937 1,决定系数R²分别为0.900 8、0.896 5和0.875 1,校正标准偏差RMSEC分别为0.007 0、0.005 4和0.005 1,预测标准偏差RMSEP分别为0.011 8、0.008 9和0.008 8。【结论】采用近红外光谱技术能够实现新疆南疆果树残枝纤维素、半纤维素和木质素三组分的快速定量检测。

关键词: 近红外光谱技术, 果树残枝, 定量分析, 纤维素, 半纤维素, 木质素

CLC Number:

S66-3

GAO Qian, WANG Yamei, WU Pingfan, ZHANG Hongmei, ZHOU Ling. Determination of Fiber Component Content in the Residual Branches of Fruit Trees in South Xinjiang Based on Near Infrared Spectroscopy[J]. Xinjiang Agricultural Sciences, 2022, 59(8): 2025-2032.

高倩, 王亚梅, 吴平凡, 张红美, 周岭. 基于近红外光谱的果树残枝纤维组分含量分析[J]. 新疆农业科学, 2022, 59(8): 2025-2032.

Figures/Tables 9

References 19

[1]	孔庆明. 大豆秸秆成分近红外光谱分析快速检测方法研究[D]. 哈尔滨, 东北农业大学, 2015.
	KONG Qingming. Study on the rapid detection method of soybean straw composition near infrared spectroscopy[D]. Harbin: Northeast Agricultural University, 2015.
[2]	杨增玲, 杨钦楷, 沈广辉, 等. 豆粕品质近红外定量分析实验室模型在线应用[J]. 农业机械学报, 2019, 50(8):358-363,371.
	YANG Zengling, YANG Qinkai, SHEN Guanghui, et al. On-line application of laboratory model for near infrared quantitative analysis of soybean meal quality[J]. Transactions of the Chinese Society of Agricultural Machinery, 2019, 50(8):358-363,371.
[3]	Huang J, Yu C. Determination of cellulose, hemicellulose and lignin content using near-infrared spectroscopy in flax fiber[J]. Textile Research Journal, 2019.
[4]	管丽媛, 王钟, 祁宁, 等. 基于近红外光谱技术的亚麻纤维化学成分含量快速测定[J]. 分析测试学报, 2020, 39(6):795-799.
	GUAN Liyuan, WANG ZHONG, Qi Ning, et al. Rapid determination of the chemical composition of flax fiber based on near-infrared spectroscopy technology[J]. Chinese Journal of Analysis Laboratory, 2020, 39(6):795-799.
[5]	谢欢, 陈争光. 遗传模拟退火算法在玉米秸秆纤维素含量检测中的应用[J]. 分析化学, 2019, 47(12):1987-1994.
	XIE Huan, CHEN Zhengguang. Application of Genetic Simulated Annealing Algorithm in the Detection of Corn Stalk Cellulose Content[J]. Chinese Journal of Analytical Chemistry, 2019, 47(12):1987-1994. DOI
[6]	任兰天, 唐飞, 邵庆勤, 等. 基于近红外光谱法快速测定秸秆堆腐过程中纤维素、半纤维素和木质素含量的研究[J]. 中国农业大学学报, 2018, 23(6):33-39.
	REN Lantian, TANG Fei, SHAO Qingqin, et al. Research on the rapid determination of cellulose, hemicellulose and lignin content during straw composting based on near-infrared spectroscopy[J]. Journal of China Agricultural University, 2018, 23(6) :33-39.
[7]	陈雪萍, 刘世尧, 尹能文, 等. 甘蓝型油菜茎秆纤维组分含量和木质素单体G/S近红外模型构建[J]. 中国农业科学, 2018, 51(4):688-696.
	CHEN Xueping, LIU Shiyao, YIN Nengwen, et al. Construction of the near-infrared model of the fiber component content and lignin monomer G/S of Brassica napus stalk[J]. Chinese Agricultural Sciences, 2018, 51(4):688-696.
[8]	刘金明, 初晓冬, 王智, 等. 玉米秸秆纤维素和半纤维素NIRS特征波长优选[J]. 光谱学与光谱分析, 2019, 39(3):743-750.
	LIU Jinming, CHU Xiaodong, WANG Zhi, et al. Optimization of NIRS characteristic wavelength of corn stover cellulose and hemicellulose[J]. Spectroscopy and Spectral Analysis, 2019, 39(3):743-750. DOI
[9]	石鲁珍, 张景川, 王彦群, 等. 马氏距离与浓度残差剔除近红外异常样品研究[J]. 中国农机化学报, 2016, 37(6):99-103.
	SHI Luzhen, ZHANG Jingchuan, WANG Yanqun, et al. Research on Mahalanobis distance and concentration residual to eliminate near-infrared abnormal samples[J]. Chinese Journal of Agricultural Machinery Chemistry, 2016, 37(6):99-103.
[10]	王世芳, 韩平, 崔广禄, 等. SPXY算法的西瓜可溶性固形物近红外光谱检测[J]. 光谱学与光谱分析, 2019, 39(3):738-742.
	WANG Shifang, HAN Ping, CUI Guanglu, et al. Detection of watermelon soluble solids by near infrared spectroscopy based on SPXY algorithm[J]. Spectroscopy and Spectral Analysis, 2019, 39(3):738-742. DOI
[11]	付苗苗, 刘梅英, 牛智有. 基于高光谱图像技术的配合饲料主要营养成分的检测方法[J]. 华中农业大学学报, 2017, 36(2):123-129.
	FU Miaomiao, LIU Meiying, NIU Zhiyou. Detection method of main nutrients in compound feed based on hyperspectral image technology[J]. Journal of HuazhongAgricultural University, 2017, 36(2):123-129.
[12]	褚小立. 近红外光谱分析技术实用手册[M]. 北京: 机械工业出版社, 2016,125.
	CHU Xiaoli. Practical Handbook of Near Infrared Spectroscopy Analysis Technology[M]. Beijing: Mechanical Industry Press, 2016, 125.
[13]	王文霞, 马本学, 罗秀芝, 等. 近红外光谱结合变量优选和GA-ELM模型的干制哈密大枣水分含量研究[J]. 光谱学与光谱分析, 2020, 40(2):543-549.
	WANG Wenxia, MA Benxue, LUO Xiuzhi, et al. Study on moisture content of dried Hami jujube based on near-infrared spectroscopy combined with variable optimization and GA-ELM model[J]. Spectroscopy and Spectral Analysis, 2020, 40(2):543-549.
[14]	何春荣, 杨宇虹, 李军会, 等. 初烤完整烟叶总植物碱的近红外光谱测量方法研究[J]. 光谱学与光谱分析, 2017, 37(10):3088-3093.
	HE Chunrong, YANG Yuhong, LI Junhui, et al. Study on the Near-Infrared Spectroscopy Measurement Method of Total Alkaloids in Freshly-cured Whole Tobacco Leaves[J]. Spectroscopy and Spectral Analysis, 2017, 37(10):3088-3093.
[15]	彭海根, 罗华平, 彭云发, 等. 近红外技术对南疆冬枣糖度无损检测的研究[J]. 农机化研究, 2014, 36(11):146-150.
	PENG Haigen, LUO Huaping, PENG Yunfa, et al. Research on the non-destructive detection of sugar content of Nanjiang winter jujube with near infrared technology[J]. Journal of Agricultural Mechanization Research, 2014, 36(11):146-150.
[16]	董春旺, 梁高震, 安霆, 等. 红茶感官品质及成分近红外光谱快速检测模型建立[J]. 农业工程学报, 2018, 34(24):306-313.
	DONG Chunwang, LIANG Gaozhen, AN Ting, et al. Establishment of a rapid detection model for the sensory quality and composition of black tea by near infrared spectroscopy[J]. Transactions of the Chinese Society of Agricultural Engineering(Transactions of the CSAE), 2018, 34(24):306-313.
[17]	周竹, 郑剑, 王允祥, 等. 雷竹笋硬度的近红外光谱检测模型优化[J]. 浙江农林大学学报, 2015, 32(6):875-882.
	ZHOU Zhu, ZHENG Jian, WANG Yunxiang, et al. Optimization of the near-infrared spectroscopy detection model for the hardness of Lei bamboo shoots[J]. Journal of Zhejiang A&F University, 2015, 32(6):875-882.
[18]	李伟, 罗华平, 索玉婷, 等. 冬枣水分高光谱快速反演模型研究[J]. 食品科技, 2020, 45(2):329-333.
	LI Wei, LUO Huaping, SUO Yuting, et al. Research on the fast inversion model of moisture hyperspectral in winter jujube[J]. Food Science and Technology, 2020, 45(2):329-333.
[19]	邱园园, 朱荣光, 黄昆鹏, 等. 真空包装冷却羊肉pH值和颜色的近红外快速无损检测[J]. 新疆农业科学, 2017, 54(11):2092-2099. DOI
	QIU Yuanyuan, ZHU Rongguang, HUANG Kunpeng, et al. NIR rapid non-destructive detection of pH value and color of vacuum-packed cooled lamb[J]. Xinjiang Agricultural Sciences, 2017, 54(11): 2092-2099. DOI

组分Composition	样本集 Sample set	样本数 Number of samples （个）	最小值 Minimum （%）	最大值 Max （%）	变幅 Luffing （%）	平均 Mean （%）	标准差 Standard deviation
纤维素 Cellulose	校正集	100	24.92	50.08	25.16	35.92	4.44
纤维素 Cellulose	验证集	35	28.76	47.48	18.72	36.91	4.32
半纤维素 Hemicellulose	校正集	100	9.92	31.88	21.96	20.08	4.53
半纤维素 Hemicellulose	验证集	37	14.68	27.1	12.42	21.64	3.25
木质素 Lignin	校正集	100	6.33	23.88	17.55	14.55	3.58
木质素 Lignin	验证集	35	10.48	20.63	10.15	14.15	2.95

组分Composition	样本集 Sample set	样本数 Number of samples （个）	最小值 Minimum （%）	最大值 Max （%）	变幅 Luffing （%）	平均 Mean （%）	标准差 Standard deviation
纤维素 Cellulose	校正集	100	24.92	50.08	25.16	35.92	4.44
纤维素 Cellulose	验证集	35	28.76	47.48	18.72	36.91	4.32
半纤维素 Hemicellulose	校正集	100	9.92	31.88	21.96	20.08	4.53
半纤维素 Hemicellulose	验证集	37	14.68	27.1	12.42	21.64	3.25
木质素 Lignin	校正集	100	6.33	23.88	17.55	14.55	3.58
木质素 Lignin	验证集	35	10.48	20.63	10.15	14.15	2.95

组分 Composition	预处理方法 Pretreatment method	相关系数 r	决定系数 R²	校正标准偏差 RMSECV	预测标准偏差 RMSEP	RPD
纤维素 Cellulose	原始光谱	0.830 4	0.680 3	0.012 6	0.019 4	1.77
	SG	0.860 1	0.716 4	0.010 8	0.018 2	1.88
	均值中心化	0.818 1	0.665 0	0.011 2	0.018 8	1.73
	一阶导	0.841 3	0.692 1	0.012 1	0.023 6	1.80
	SNV	0.846 2	0.705 6	0.011 6	0.019 1	1.84
半纤维素 Hemicellulose	原始光谱	0.812 3	0.552 9	0.017 6	0.028 1	1.50
	SG	0.836 4	0.585 5	0.011 2	0.018 2	1.56
	均值中心化	0.708 8	0.406 4	0.018 0	0.029 4	1.30
	一阶导	0.801 4	0.574 8	0.016 3	0.021 6	1.53
	SNV	0.828 6	0.578 1	0.012 1	0.019 6	1.54
木质素 Lignin	原始光谱	0.802 6	0.606 7	0.012 0	0.017 6	1.59
	SG	0.810 4	0.619 7	0.008 9	0.015 3	1.62
	均值中心化	0.758 9	0.430 1	0.011 6	0.019 8	1.32
	一阶导	0.808 7	0.602 3	0.013 4	0.018 9	1.59
	SNV	0.808 9	0.608 3	0.010 3	0.016 2	1.60

组分 Composition	预处理方法 Pretreatment method	相关系数 r	决定系数 R²	校正标准偏差 RMSECV	预测标准偏差 RMSEP	RPD
纤维素 Cellulose	原始光谱	0.830 4	0.680 3	0.012 6	0.019 4	1.77
	SG	0.860 1	0.716 4	0.010 8	0.018 2	1.88
	均值中心化	0.818 1	0.665 0	0.011 2	0.018 8	1.73
	一阶导	0.841 3	0.692 1	0.012 1	0.023 6	1.80
	SNV	0.846 2	0.705 6	0.011 6	0.019 1	1.84
半纤维素 Hemicellulose	原始光谱	0.812 3	0.552 9	0.017 6	0.028 1	1.50
	SG	0.836 4	0.585 5	0.011 2	0.018 2	1.56
	均值中心化	0.708 8	0.406 4	0.018 0	0.029 4	1.30
	一阶导	0.801 4	0.574 8	0.016 3	0.021 6	1.53
	SNV	0.828 6	0.578 1	0.012 1	0.019 6	1.54
木质素 Lignin	原始光谱	0.802 6	0.606 7	0.012 0	0.017 6	1.59
	SG	0.810 4	0.619 7	0.008 9	0.015 3	1.62
	均值中心化	0.758 9	0.430 1	0.011 6	0.019 8	1.32
	一阶导	0.808 7	0.602 3	0.013 4	0.018 9	1.59
	SNV	0.808 9	0.608 3	0.010 3	0.016 2	1.60

组分Composition	波段选择方法 Spectral wavelength selection method	变量数 Number of variables	相关系数 r	决定系数 R²	校正标准偏差 RMSECV	预测标准偏差 RMSEP	RPD
纤维素 Cellulose	全光谱建模	1557	0.860 1	0.716 4	0.0108	0.018 2	1.88
	SPA	44	0.890 4	0.783 1	0.010 5	0.0177	2.15
	CARS	28	0.950 3	0.900 8	0.007 0	0.0118	3.18
半纤维素 Hemicellulose	全光谱建模	1557	0.836 4	0.585 5	0.011 2	0.018 2	1.55
	SPA	52	0.843 8	0.634 0	0.010 5	0.017 1	1.65
	CARS	27	0.948 7	0.896 5	0.005 4	0.008 9	3.11
木质素 Lignin	全光谱建模	1557	0.810 4	0.619 7	0.008 9	0.015 3	1.62
	SPA	58	0.823 0	0.659 4	0.008 5	0.014 5	1.71
	CARS	21	0.937 1	0.875 1	0.005 1	0.008 8	2.83
