Xinjiang Agricultural Sciences ›› 2023, Vol. 60 ›› Issue (7): 1580-1588.DOI: 10.6048/j.issn.1001-4330.2023.07.003
• Crop Genetics and Breeding·Germplasm Resources·Molecular Genetics·Soil Fertilizer • Previous Articles Next Articles
LIN Ling1,2,3(), ZHU Yujie1, FENG Lei1, TANG Guangmu2, ZHANG Yunshu2, XU Wanli2()
Received:
2022-09-27
Online:
2023-07-20
Published:
2023-07-11
Correspondence author:
XU Wanli (1971-), male, Baoji, Shaanxi, researcher, Doctor, Research direction:Agricultural and forestry waste resources recovery, soil fertilizer cultivation and improvement,(E-mail)wlxu2005@163.com
Supported by:
林玲1,2,3(), 朱玉洁1, 冯雷1, 唐光木2, 张云舒2, 徐万里2()
通讯作者:
徐万里(1971-),男,陕西宝鸡人,研究员,博士,研究方向为农林废弃物资源化、土壤培肥与改良,(E-mail)wlxu2005@163.com
作者简介:
林玲(1992-),女,重庆丰都人,硕士研究生,研究方向为农林废弃物资源化、土壤培肥与改良,(E-mail)1041782931@qq.com
基金资助:
CLC Number:
LIN Ling, ZHU Yujie, FENG Lei, TANG Guangmu, ZHANG Yunshu, XU Wanli. Features of aged cotton stalk charcoal and its effect on ammonia volatilization from sand soil[J]. Xinjiang Agricultural Sciences, 2023, 60(7): 1580-1588.
林玲, 朱玉洁, 冯雷, 唐光木, 张云舒, 徐万里. 棉秆炭老化特性及其对风沙土氨挥发的影响[J]. 新疆农业科学, 2023, 60(7): 1580-1588.
Add to citation manager EndNote|Ris|BibTeX
URL: http://www.xjnykx.com/EN/10.6048/j.issn.1001-4330.2023.07.003
处理 Treatment | 比表面积 Specific surface area (m2/ g) | 总孔体积 The total pore volume (cm3/g) | 平均孔径 The average pore diameter (nm) | 介孔体积 Mesoporous volume (cm3/g) |
---|---|---|---|---|
BC | 17.76±0.25b | 0.030±0.004b | 6.83±0.84b | 0.025±0.004b |
DBC | 9.03±2.04c | 0.026±0.002b | 11.51±1.57a | 0.024±0.002b |
EBC | 10.22±0.70c | 0.028±0.003b | 11.32±0.25a | 0.026±0.001b |
CBC | 51.09±6.67a | 0.071±0.014a | 5.56±0.73b | 0.059±0.013a |
Tab.1 Specific surface area and pore size of different aged cotton stalk charcoal
处理 Treatment | 比表面积 Specific surface area (m2/ g) | 总孔体积 The total pore volume (cm3/g) | 平均孔径 The average pore diameter (nm) | 介孔体积 Mesoporous volume (cm3/g) |
---|---|---|---|---|
BC | 17.76±0.25b | 0.030±0.004b | 6.83±0.84b | 0.025±0.004b |
DBC | 9.03±2.04c | 0.026±0.002b | 11.51±1.57a | 0.024±0.002b |
EBC | 10.22±0.70c | 0.028±0.003b | 11.32±0.25a | 0.026±0.001b |
CBC | 51.09±6.67a | 0.071±0.014a | 5.56±0.73b | 0.059±0.013a |
处理 Treatment | pH | 电导率 Electrical conductivity (mS/cm) |
---|---|---|
BC | 10.30±0.03a | 8.08±0.07a |
DBC | 10.21±0.00a | 6.71±0.16b |
EBC | 10.29±0.02a | 7.75±0.21a |
CBC | 5.16±0.20b | 0.77±0.08c |
Tab.2 pH value and electrical conductivity of different aged cotton stalk charcoal
处理 Treatment | pH | 电导率 Electrical conductivity (mS/cm) |
---|---|---|
BC | 10.30±0.03a | 8.08±0.07a |
DBC | 10.21±0.00a | 6.71±0.16b |
EBC | 10.29±0.02a | 7.75±0.21a |
CBC | 5.16±0.20b | 0.77±0.08c |
[1] | 陈温福, 张伟明, 孟军, 等. 生物炭应用技术研究[J]. 中国工程科学, 2011, 13(2):83-89. |
CHEN Wenfu, ZHANG Weiming, MENG Jun, et al. Researches on biochar application technology[J]. Strategic Study of CAE, 2011, 13(2):83-89. | |
[2] |
Colantoni, Evic, Lord, et al. Characterization of biochar produced from pyrolysis of pelletized agricultural residues[J]. Renewable and Sustainable Energy Reviews, 2016, 64:187-194.
DOI URL |
[3] | 张云舒, 唐光木, 葛春辉, 等. 生物炭对灌耕风沙土土壤性质及玉米产量的影响[J]. 干旱地区农业研究, 2018, 36(6):180-183. |
ZHANG Yunshu, TANG Guangmu, GE Chunhui, et al. Effects of biochar on soil properties and corn yield of irrigated sandy soil[J]. AgriculturalResearch in the Arid Areas, 2018, 36(6):180-183. | |
[4] | 顾美英, 徐万里, 唐光木, 等. 生物炭对灰漠土和风沙土土壤微生物多样性及与氮素相关微生物功能的影响[J]. 新疆农业科学, 2014, 51(5):926-934. |
GU Meiying, XU Wanli, TANG Guangmu, et al. Effects of Biochar on Soil Microbial Diversity and Function Related with N Transformation in Grey Desert Soil and Aeolian Sandy Soil in Xinjiang[J]. Xinjiang Agricultural Sciences, 2014, 51(5):926-934. | |
[5] | 李涛, 王小国, 胡廷旭. 生物炭对紫色土农田土壤NO排放的影响[J]. 土壤, 2016, 48(5):879-886. |
LI Tao, WANG Xiaoguo, HU Yanxu. Impact of Biochar on NO Emission from Cropland of Purple Soil[J]. Soils, 2016, 48(5):879-886. | |
[6] |
许云翔, 何莉莉, 陈金媛, 等. 生物炭对农田土壤氨挥发的影响机制研究进展[J]. 应用生态学报, 2020, 31(12):4312- 4320.
DOI |
XU Yunxiang, HE Lili, CHEN Jinyuan, et al. Effects of biochar on ammonia volatilization from farmland soil:A review[J]. Chinese Journal of Applied Ecology, 2020, 31(12):4312- 4320.
DOI |
|
[7] |
WANG Liuwei, O'Connor David, Rinklebe Jorg, et al. Biochar Aging:Mechanisms, Physicochemical Changes, Assessment, And Implications for Field Applications[J]. Environmental Science and Technology, 2020, 54(23):14797-14814.
DOI PMID |
[8] | 朱影, 庄国强, 吴尚华, 等. 农田土壤氨挥发的过程和控制技术研究[J]. 环境保护科学, 2020, 46(6):88-96. |
ZHU Ying, ZHUANG Guoqiang, WU Shanghua, et al. Ammonia Volatilization Process and Control Technology of Farmland Soil[J]. Environmental Protection Science, 2020, 46(6):88-96. | |
[9] | 卢丽丽, 吴根义. 农田氨排放影响因素研究进展[J]. 中国农业大学学报, 2019, 24(1):149-162. |
LU Lili, WU Genyi. Advances in affecting factors of ammonia emission in farmland[J]. Journal of China Agricultural University, 2019, 24(1):149-162. | |
[10] | 肖其亮, 朱坚, 彭华, 等. 稻田氨挥发损失及减排技术研究进展[J]. 农业环境科学学报, 2021, 40(1):16-25. |
XIAO Qiliang, ZHU Jian, PENG Hua, et al. Ammonia volatilization loss and emission reduction measures in paddy fields[J]. Journal of Agro-Environment Science, 2021, 40(1):16-25. | |
[11] |
YANG Fan, CAO Xinde, GAO Bin, et al. Short-term effects of rice straw biochar on sorption, emission, and transformation of soil NH4+-N[J]. Environmental Science and Pollution Research, 2015, 22:9184-9192.
DOI URL |
[12] | SUN Haijun, LU Haiying, CHU Liu, et al. Biochar applied with appropriate rates can reduce N leaching, keep N retention and not increase NH3 volatilization in a coastal saline soil[J]. Science of the Total EnvironmentVolume, 2017, 575:820-825. |
[13] |
Mandal Sanchita, Thangarajan Ramya, Bolan Nanthi S, et al. Biochar-induced concomitant decrease in ammonia volatilization and increase in nitrogen use efficiency by wheat[J]. Chemosphere, 2016, 142:120-127.
DOI PMID |
[14] |
SHA Zhipeng, LI Qianqian, LV Tianian, et al. Response of ammonia volatilization to biochar addition:A meta-analysist[J]. Science of the Total Environment, 2018, 655:1387-1396.
DOI URL |
[15] | 鞠文亮, 荆延德. 陈化处理对棉花秸秆生物炭理化性质的影响[J]. 环境科学学报, 2017, 37(10):3853-3861. |
JU Wenliang, JIN Yande. Efectof aging treatm ent on physicochemical characteristics of cotton straw biochar[J]. Acta Science Circumstantiae, 2017, 37(10):3853-3861. | |
[16] | 闵露娟, 柳金明, 张鹏, 等. 不同老化过程对生物炭理化性质及吸附邻苯二甲酸酯的影响[J]. 农业环境科学学报, 2021, 40(4):806-814. |
MIN Lujuan, LIU Jinming, ZHANG Peng, et al. Influences of different aging processes on biochar physicochemical properties and the adsorption of phthalic acid esters[J]. Journal of Agro-Environment Science, 2021, 40(4):806-814. | |
[17] | Rosa José María de la, Rosado Mario, Paneque Marina, et al. Effects of aging under field conditions on biochar structure and composition:Implications for biochar stability in soils[J]. Science of the Total Environmen, 2018, 613-614:969-976. |
[18] |
TAN Lianshuai, MA Zhanghua, YANG Kaiqi, et al. Effect of three artificial aging techniques on physicochemical properties and Pb adsorption capacities of different biochars[J]. Science of the Total Environment, 2019, 699:134223.
DOI URL |
[19] | 汪艳如, 侯杰发, 郭建华, 等. 冻融循环对牦牛粪生物炭吸附氨氮的影响[J]. 农业环境科学学报, 2017, 36(3):566-573. |
WANG Yanru, HOU Jiefa, GUO Jianhua, et al. Effects of freeze-thaw cycles on ammonium-nitrogen adsorption of yak dung biochip[J]. Journal of Agro-Environment Science, 2017, 36(3):566-573.
DOI URL |
|
[20] | 张雪, 刘笑生, 沈露露, 等. 老化作用对巨菌草茎生物炭内源铜镉活性的影响[J]. 农业环境科学学报, 2020, 39(3):563-571. |
ZHANG Xue, LIU Xiaosheng, SHENG Lulu, et al. Effects of ageing on the availability of endogenous copper and cadmium in biochar derived from Pennisetum sp.stems[J]. Journal of Agro-Environment Science, 2020, 39(3):563-571. | |
[21] |
SUN Lei, CHEN Dongmei, WAN Shungang, et al. Performance, kinetics, and equilibrium of methylene blue adsorption on biochar derived from eucalyptus saw dust modified with citric, tartaric, and acetic acids[J]. Bioresource Technology, 2015, 198:300-308.
DOI PMID |
[22] | XU Yan, LIU Yunguo, LIU Shaobo, et al. Enhanced adsorption of methylene blue by citric acid modification of biochar derived from water hyacinth (Eichornia crassipes)[J]. Environmental Science & Pollution Research, 2016, 23(23):1-13. |
[23] | 阴文敏, 关卓, 刘琛, 等. 生物炭施用及老化对紫色土中抗生素吸附特征的影响[J]. 环境科学, 2019, 40(6):2920-2929. |
YIN Wenmin, GUAN Zhuo, LIU Chen, et al. Effects of Biochar Application and Ageing on the Adsorption of Antibiotics in Purple Soil[J]. Environmental Science, 2019, 40(6):2920-2929. | |
[24] | 姚红宇, 唐光木, 葛春辉, 等. 炭化温度和时间与棉秆炭特性及元素组成的相关关系[J]. 农业工程学报, 2013, 29(7):199-206. |
YAO Hongyu, TANG Guangmu, GE Chunhui, et al. Characteristics and elementary composition of cotton stalk-char in different carbonization temperature and time[J]. Transactions of the Chinese Society of Agricultural Engineering, 2013, 29(7):199-206. | |
[25] | 林志锋, 黄忠泊, 刘长风. 有机肥料氮、磷、钾的化学分析方法[J]. 中国土壤与肥料, 2006,(5):62-65. |
LIN Zhifeng, HUANG Zhongbo, LIU Changfeng. Chemical analysis method applying in determining organic fertilizer nitrogen phosphorus and potassium levels[J]. Soil and Fertilizer Sciences in China, 2006,(5):62-65. | |
[26] | 杨放, 李心清, 王兵, 等. 热解材料对生物炭理化性质的影响[J]. 农业环境科学学报, 2015, 34(9):1822-1828. |
YANG Fang, LI Xinqing, WANG Bing, et al. Effects of Different Feed stocks on Physicochemical Characteristics of Pyrolyzed Biochars[J]. Journal of Agro-Environment Science, 2015, 34(9):1822-1828. | |
[27] |
CUI Hongbiao, LI Detian, LIU Xiaosheng, et al. Dry-wet and freeze-thaw aging activate endogenous copper and cadmium in biochar[J]. Journal of Cleaner Production, 2020, 288:125605.
DOI URL |
[28] |
Ameur Dominik, Zehetner Franz, Johnen Simone, et al. Activated biochar alters activities of carbon and nitrogen acquiring soil enzymes[J]. Pedobiologia, 2018, 69:1-10.
DOI URL |
[29] |
王朝旭, 陈绍荣, 张峰, 等. 老化玉米秸秆生物炭对碱性农田土壤氨氧化作用的影响[J]. 生态环境学报, 2018, 27(1):31-39.
DOI |
WANG Chaoxu, CHEN Shaorong, ZHANG Feng, et al. Effects of Aged Maize Straw-derived Biochars on Ammonia Oxidation in An Alkaline Farmland Soil[J]. Ecology and Environmental Sciences, 2018, 27(1):31-39. | |
[30] |
ZHANG Shiqiu, YANG Xue, JU Meiting, et al. Mercury adsorption to aged biochar and its management in China[J]. Environmental Science and Pollution Research, 2019, 26(5):4867-4877.
DOI |
[31] | 刘艳, 王聪颖, 史志明, 等. 老化生物炭对小白菜积累重金属的影响[J]. 山西农业大学学报(自然科学版), 2019, 39(3):58-64. |
LIU Yan, WANG Congyin, SHI Zhiming, et al. Effect of aged biochar on the accumulation of heavy metalsinpakchoi[J]. Journal of Shanxi Agricultural University (Natural Science Ed.), 2019, 39(3):58-64. | |
[32] | 秦蓓. 棉秆炭对新疆灌耕灰漠土和风沙土pH值及氨挥发的影响[D]. 乌鲁木齐: 新疆农业大学, 2018. |
QIN Bei. Influence of cotton stalk-char on pH and ammonia volatilization of Xinjiang cultivated gray desert soil and sandy soil[D]. Urumqi: Xinjiang Agricultural University, 2018. | |
[33] | LIU Guocheng, CHEN Lei, JIANG Zhixiang, et al. Aging impacts of low molecular weight organic acids (LMWOAs) on furfural production residue-derived biochars:Porosity, functional properties, and inorganic minerals[J]. Science of the Total Environment, 2017, 607- 608(12):1428-1436. |
[34] | 王朝旭, 陈绍荣, 张峰, 等. 玉米秸秆生物炭及其老化对石灰性农田土壤氨挥发的影响[J]. 农业环境科学学报, 2018, 37(10):2350- 2358. |
WANG Chaoxu, CHEN Shaorong, ZHANG Feng, et al. Effects of fresh and aged maize straw-derived biochars on ammonia volatilization in a calcareous arable soil[J]. Journal of Agro-Environment Science, 2018, 37(10):2350-2358 | |
[35] |
DONG Yubing, WU Zhen, ZHANG Xi, et al. Dynamic responses of ammonia volatilization to different rates of fresh and field-aged biochar in a rice-wheat rotation system[J]. Field Crops Research, 2019, 241:107568.
DOI URL |
[36] | 张丰, 刘畅, 王喆, 等. 不同吸附特性的稻草生物炭对稻田氨挥发和水稻产量的影响[J]. 农业工程学报, 2021, 37(9):100-109. |
ZANG Feng, LIU Chang, WANG Zhe, et al. Effects of rice straw biochar with different adsorption characteristics on ammonia volatilization from paddy field and rice yield[J]. Transactions of the Chinese Society of Agricultural Engineering, 2021, 37(9):100-109. | |
[37] |
Esfandbod M, Phillips I R, Miller B, et al. Aged acidic biochar increases nitrogen retention and decreases ammonia volatilization in alkaline bauxite residue sand[J]. Ecological Engineering, 2017, 98:157-165.
DOI URL |
