Xinjiang Agricultural Sciences ›› 2022, Vol. 59 ›› Issue (9): 2232-2239.DOI: 10.6048/j.issn.1001-4330.2022.09.018
• Horticultural Special Local Products·Storage and Preservation Processing·Soil Fertilizer·Water Saving Irrigation·Prataculture·Food Process Engineering • Previous Articles Next Articles
MA Bin(), WANG Shuai, WU Yiyan, JIANG Yan()
Received:
2021-12-01
Online:
2022-09-20
Published:
2023-01-16
Correspondence author:
JIANG Yan
Supported by:
通讯作者:
姜艳
作者简介:
马彬(1994-),男,新疆伊宁人,硕士研究生,研究方向为土壤生态与环境安全。(E-mail)mms151532@163.com
基金资助:
CLC Number:
MA Bin, WANG Shuai, WU Yiyan, JIANG Yan. Study on the Tire Effect of Farmland Shelter Forest in Arid Desert Area[J]. Xinjiang Agricultural Sciences, 2022, 59(9): 2232-2239.
马彬, 王帅, 吴依衍, 姜艳. 干旱荒漠区农田防护林正负效应及其影响机制[J]. 新疆农业科学, 2022, 59(9): 2232-2239.
Add to citation manager EndNote|Ris|BibTeX
URL: http://www.xjnykx.com/EN/10.6048/j.issn.1001-4330.2022.09.018
测点 Measuring point | 6月22日 (苗期 Seedling stage ) | 7月16日 (铃期 Bell period) | 8月2日 (蕾期 Bud stage) |
---|---|---|---|
0.1H | 5.14e | 24.12e | 46.39d |
0.25H | 11.45d | 88.25d | 177.45c |
0.5H | 40.04c | 139.55c | 241.76b |
1H | 50.17b | 154.60b | 261.21a |
2H | 60.89a | 161.07a | 267.31a |
3H | 61.04a | 164.34a | 271.75a |
Table 1 Changes in cotton biomass at different distances(%)
测点 Measuring point | 6月22日 (苗期 Seedling stage ) | 7月16日 (铃期 Bell period) | 8月2日 (蕾期 Bud stage) |
---|---|---|---|
0.1H | 5.14e | 24.12e | 46.39d |
0.25H | 11.45d | 88.25d | 177.45c |
0.5H | 40.04c | 139.55c | 241.76b |
1H | 50.17b | 154.60b | 261.21a |
2H | 60.89a | 161.07a | 267.31a |
3H | 61.04a | 164.34a | 271.75a |
项目 Item | 光照强度 Light intensity | 空气湿度 Air humidity | 风速 Wind speed | 空气温度 Air temperature | 蒸发量 Evaporation |
---|---|---|---|---|---|
相关系数 Correlation coefficient | 0.995 | 0.237 | 0.963 | 0.923 | 0.920 |
P | 0.000 | 0.326 | 0.001 | 0.004 | 0.005 |
Table 2 Leading factors of meteorological environment in the shelterbelt zone
项目 Item | 光照强度 Light intensity | 空气湿度 Air humidity | 风速 Wind speed | 空气温度 Air temperature | 蒸发量 Evaporation |
---|---|---|---|---|---|
相关系数 Correlation coefficient | 0.995 | 0.237 | 0.963 | 0.923 | 0.920 |
P | 0.000 | 0.326 | 0.001 | 0.004 | 0.005 |
测点 Measuring point | 4月30日-5月30日 | 6月10日-7月10日 | 7月25日-9月15日 |
---|---|---|---|
0.1H | 0.042b | 0.088c | 0.078c |
0.25H | 0.056b | 0.127c | 0.093c |
0.5H | 0.085b | 0.224c | 0.256c |
1H | 0.348b | 0.915b | 0.750b |
2H | 0.736a | 1.514a | 1.407a |
3H | 0.757a | 1.558a | 1.429a |
Table 3 Changes of light intensity in cotton fields at different distances
测点 Measuring point | 4月30日-5月30日 | 6月10日-7月10日 | 7月25日-9月15日 |
---|---|---|---|
0.1H | 0.042b | 0.088c | 0.078c |
0.25H | 0.056b | 0.127c | 0.093c |
0.5H | 0.085b | 0.224c | 0.256c |
1H | 0.348b | 0.915b | 0.750b |
2H | 0.736a | 1.514a | 1.407a |
3H | 0.757a | 1.558a | 1.429a |
7月16日 | 测点 Point | 0.1H | 0.25H | 0.5H | 1H | 2H | 3H |
---|---|---|---|---|---|---|---|
有机质(g/kg) Organic matter g/kg | 11.08 | 11.56 | 12.03 | 12.40 | 13.12 | 13.08 | |
Δ | -2 | -1.52 | -1.05 | -0.68 | 0.04 | 0 | |
平均 Average | -1.04 | 较3H降低7.97% | |||||
8月20日 | 测点 Point | 0.1H | 0.25H | 0.5H | 1H | 2H | 3H |
有机质(g/kg) Organic matter g/kg | 11.25 | 11.58 | 12.29 | 13.17 | 13.66 | 13.48 | |
Δ | -2.23 | -1.9 | -1.19 | -0.31 | 0.18 | 0 | |
平均 Average | -1.09 | 平均较3H降低8.09% |
Table 4 Soil organic matter content in different locations of the shelterbelt
7月16日 | 测点 Point | 0.1H | 0.25H | 0.5H | 1H | 2H | 3H |
---|---|---|---|---|---|---|---|
有机质(g/kg) Organic matter g/kg | 11.08 | 11.56 | 12.03 | 12.40 | 13.12 | 13.08 | |
Δ | -2 | -1.52 | -1.05 | -0.68 | 0.04 | 0 | |
平均 Average | -1.04 | 较3H降低7.97% | |||||
8月20日 | 测点 Point | 0.1H | 0.25H | 0.5H | 1H | 2H | 3H |
有机质(g/kg) Organic matter g/kg | 11.25 | 11.58 | 12.29 | 13.17 | 13.66 | 13.48 | |
Δ | -2.23 | -1.9 | -1.19 | -0.31 | 0.18 | 0 | |
平均 Average | -1.09 | 平均较3H降低8.09% |
7月16日 | 测点 Point | 0.1H | 0.25H | 0.5H | 1H | 2H | 3H |
---|---|---|---|---|---|---|---|
全氮(g/kg) Total nitrogen g/kg | 0.33 | 0.37 | 0.40 | 0.43 | 0.45 | 0.44 | |
Δ | -0.11 | -0.07 | -0.04 | -0.01 | 0.01 | 0 | |
平均 Average | -0.04 | 平均较3H下降10.17% | |||||
8月20日 | 测点 Point | 0.1H | 0.25H | 0.5H | 1H | 2H | 3H |
全氮(g/kg) Total nitrogen g/kg | 0.29 | 0.31 | 0.36 | 0.40 | 0.47 | 0.46 | |
Δ | -0.17 | -0.15 | -0.10 | -0.06 | 0.01 | 0 | |
平均 Average | -0.09 | 平均较3H下降20.55% |
Table 5 Soil total nitrogen content at different locations from the shelterbelt
7月16日 | 测点 Point | 0.1H | 0.25H | 0.5H | 1H | 2H | 3H |
---|---|---|---|---|---|---|---|
全氮(g/kg) Total nitrogen g/kg | 0.33 | 0.37 | 0.40 | 0.43 | 0.45 | 0.44 | |
Δ | -0.11 | -0.07 | -0.04 | -0.01 | 0.01 | 0 | |
平均 Average | -0.04 | 平均较3H下降10.17% | |||||
8月20日 | 测点 Point | 0.1H | 0.25H | 0.5H | 1H | 2H | 3H |
全氮(g/kg) Total nitrogen g/kg | 0.29 | 0.31 | 0.36 | 0.40 | 0.47 | 0.46 | |
Δ | -0.17 | -0.15 | -0.10 | -0.06 | 0.01 | 0 | |
平均 Average | -0.09 | 平均较3H下降20.55% |
项目 Item | 有机质 Organic matter | 全氮 Total nitrogen | 碱解氮 Alkaline Nitrogen | 速效磷 Available Phosphorus | 速效钾 Available Potassium | 全盐 Full salt | pH | 土壤含水率 Soil moisture |
---|---|---|---|---|---|---|---|---|
相关系数 Correlation coefficient | 0.980 | 0.992 | 0.934 | 0.901 | 0.923 | 0.798 | 0.367 | 0.972 |
P | 0.000 | 0.000 | 0.003 | 0.000 | 0.001 | 0.029 | 0.237 | 0.001 |
Table 6 Soil fertility factors of the protection forest belt
项目 Item | 有机质 Organic matter | 全氮 Total nitrogen | 碱解氮 Alkaline Nitrogen | 速效磷 Available Phosphorus | 速效钾 Available Potassium | 全盐 Full salt | pH | 土壤含水率 Soil moisture |
---|---|---|---|---|---|---|---|---|
相关系数 Correlation coefficient | 0.980 | 0.992 | 0.934 | 0.901 | 0.923 | 0.798 | 0.367 | 0.972 |
P | 0.000 | 0.000 | 0.003 | 0.000 | 0.001 | 0.029 | 0.237 | 0.001 |
模型变量 Variables | 非标准化系数 Unstandardized coefficients | 标准化系数 Standardized coefficient | P值 P value | R | Sig | |
---|---|---|---|---|---|---|
B | 标准误差 Standard error | 贝塔 Beta | ||||
常量 Constant | -45.486 | 1.849 | 0.002 | 0.798 | 0.044 | |
光照强度 Light intensity | 98.137 | 3.718 | 0.789 | 0.001 | ||
有机质 Organic matter | 1.285 | 1.054 | 0.013 | 0.014 | ||
全氮 Total nitrogen | 15.351 | 2.641 | 0.214 | 0.025 | ||
碱解氮 Alkaline Hydrolyzed Nitrogen | 10.369 | 2.336 | 0.156 | 0.001 | ||
土壤水分 Soil Moisture | 23.389 | 5.574 | 0.282 | 0.000 |
Table 7 Multiple stepwise regression analysis of landlord factors in shelterbelt threats
模型变量 Variables | 非标准化系数 Unstandardized coefficients | 标准化系数 Standardized coefficient | P值 P value | R | Sig | |
---|---|---|---|---|---|---|
B | 标准误差 Standard error | 贝塔 Beta | ||||
常量 Constant | -45.486 | 1.849 | 0.002 | 0.798 | 0.044 | |
光照强度 Light intensity | 98.137 | 3.718 | 0.789 | 0.001 | ||
有机质 Organic matter | 1.285 | 1.054 | 0.013 | 0.014 | ||
全氮 Total nitrogen | 15.351 | 2.641 | 0.214 | 0.025 | ||
碱解氮 Alkaline Hydrolyzed Nitrogen | 10.369 | 2.336 | 0.156 | 0.001 | ||
土壤水分 Soil Moisture | 23.389 | 5.574 | 0.282 | 0.000 |
