Optimization of drip irrigation parameter combinations for salinized cotton fields

doi:10.6048/j.issn.1001-4330.2025.07.019

Abstract

Abstract:

【Objective】 To clarify the optimal drip irrigation parameter combinations for salinized cotton fields in Karamay, northern Xinjiang. 【Methods】 Two irrigation quotas (W₁: 52.5 mm, W₂: γh(S₀-S₁)/K mm) and four emitter flow rate × emitter spacing combinations (T₁: 1.4 L/h×20 cm, T₂: 2.0 L/h×30 cm, T₃: 2.4 L/h×30 cm, T₄: 2.7 L/h×30 cm) were set in the experiment and the interactive effects of these combinations on multiple indicators, including soil water-salt dynamics, crop growth, and yield, were analyzed. Meanwhile, multi-level weighting system was established using the Analytic Hierarchy Process (AHP) and the CRITIC weighting method to evaluate 11 indicators across three categories. Game theory-based combination weighting was applied to determine the final weights for single indicators. A fuzzy matter-element model was used to construct a comprehensive evaluation system for drip irrigation parameter combinations in salinized cotton fields. Furthermore, a mathematical model for soil water-salt interaction under different drip irrigation parameters was developed with the dual objectives of salinity control and high yield. 【Results】 Irrigation quota and emitter flow rate significantly affected salinity leaching efficiency, crop growth, and yield (P < 0.05). Increasing the leaching quota effectively enhanced root zone water content and salinity leaching efficiency. The optimal values for each indicator were observed under the W₂ irrigation quota, with trends showing an initial increase and subsequent decrease as the emitter flow rate increased. Among the treatments, T₂ outperformed T₃ in lower root zone salinity leaching efficiency and plant height. However, under the comprehensive evaluation system, T₃W₂ was identified as the optimal drip irrigation parameter combination. 【Conclusion】 The optimal irrigation volume and emitter flow rate to be 5,631 m³/hm² and 2.3 L/h, respectively.

Key words: water and salt; salinity leaching; drip irrigation parameters; cotton growth; comprehensive evaluation

摘要：

【目的】研究新疆北疆克拉玛依地区盐渍化棉田滴灌技术参数组合。【方法】设置2个灌水定额(W₁:52.5 mm、W₂:γh(S0-S1)/K mm),4个(滴头流量×间距)组合(T₁:1.4 L/h×20 cm、T₂:2.0 L/h×30 cm、T₃:2.4 L/h×30 cm、T₄:2.7 L/h×30 cm)。分析不同滴灌技术参数组合交互对棉花水盐、生长、产量多个指标的影响。采用AHP层次分析法和CRITIC权重法对3类因素11个指标进行多层赋权,运用博弈论的组合赋权法获得各单一指标最终权重,基于模糊物元模型建盐渍化棉田滴灌技术参数组合综合评价体系,并以控盐、高产为目标建立不同滴灌技术参数条件下的盐渍化棉田水盐交互响应数学模型。【结果】灌水定额和滴头流量对盐分淋洗效率、作物生长及产量影响显著(P<0.05)。增加淋洗定额可以有效提高根区含水率、盐分淋洗效率。各个指标最优处理均出现在 W₂ 灌水定额中,并随着滴头流量的增加呈现先增加后减小的趋势,其中 T₂ 处理仅在根区下层盐分淋洗效率、株高等指标上优于 T₃ 处理,在盐渍化棉田滴灌技术参数组合综合评价体系下, T₃W₂ 为最优滴灌技术参数组合。【结论】最优灌水量、滴头流量分别为5 631 m³/hm²、2.3 L/h。

关键词: 水盐, 盐分淋洗, 滴灌技术参数, 棉花生长, 综合评价

LUO Youyang, XIE Xiangwen, YANG Pengnian, Milixiati Minadola, XU Yongmei. Optimization of drip irrigation parameter combinations for salinized cotton fields[J]. Xinjiang Agricultural Sciences, 2025, 62(7): 1743-1754.

罗幼洋, 谢香文, 杨鹏年, 米力夏提·米那多拉, 许咏梅. 盐渍化棉田滴灌技术参数组合优选[J]. 新疆农业科学, 2025, 62(7): 1743-1754.

Figures/Tables 17

References 30

[1]	Zhang Y J, Li Y, Liang T T, et al. Field-grown cotton shows genotypic variation in agronomic and physiological responses to waterlogging[J]. Field Crops Research, 2023, 302: 109067.
[2]	吕宁, 石磊, 戴昱余, 等. 新疆盐碱地治理利用研究回顾与启示[J]. 灌溉排水学报, 2024, 43(12): 1-10.
	LYU Ning, SHI Lei, DAI Yuyu, et al. Reclamation of saline-alkali soils in Xinjiang: a review[J]. Journal of Irrigation and Drainage, 2024, 43(12): 1-10.
[3]	陶汪海, 邓铭江, 王全九, 等. 西北旱区农业高质量发展体系的生态农业内涵与路径[J]. 农业工程学报, 2023, 39(20): 221-232.
	TAO Wanghai, DENG Mingjiang, WANG Quanjiu, et al. Ecological agriculture connotation and pathway of high-quality agricultural development system in Northwest arid region[J]. Transactions of the Chinese Society of Agricultural Engineering, 2023, 39(20): 221-232.
[4]	Yan F L, Zhang F C, Fan J L, et al. Optimization of irrigation and nitrogen fertilization increases ash salt accumulation and ions absorption of drip-fertigated sugar beet in saline-alkali soils[J]. Field Crops Research, 2021, 271: 108247.
[5]	Wang H D, Wu L F, Cheng M H, et al. Coupling effects of water and fertilizer on yield, water and fertilizer use efficiency of drip-fertigated cotton in northern Xinjiang, China[J]. Field Crops Research, 2018, 219: 169-179.
[6]	赵玉, 赵嘉滨, 范雯婧, 等. 基于作物水分亏缺指数和盐分淋洗系数的新疆棉田节水控盐优化方法[J]. 农业工程学报, 2024, 40(12): 96-108.
	ZHAO Yu, ZHAO Jiabin, FAN Wenjing, et al. Optimizing the water-saving and salt-regulating method for cotton field in Xinjiang of China based on plant water deficit index and salt leaching coefficient[J]. Transactions of the Chinese Society of Agricultural Engineering, 2024, 40(12): 96-108.
[7]	陈绪兰, 孙春梅, 刘萍. 棉花“干播湿出” 技术在新疆库尔勒推广实践[J]. 中国棉花, 2021, 48(5): 41-42, 45. DOI
	CHEN Xulan, SUN Chunmei, LIU Ping. The practice of cotton “sowing drily and emerging wet” technology in Korla, Xinjiang[J]. China Cotton, 2021, 48(5): 41-42, 45. DOI
[8]	Min W, Guo H J, Zhou G W, et al. Root distribution and growth of cotton as affected by drip irrigation with saline water[J]. Field Crops Research, 2014, 169: 1-10.
[9]	冯棣, 张俊鹏, 孙池涛, 等. 不同生育阶段盐分胁迫对棉花生长和水分生理指标的影响[J]. 生态学杂志, 2014, 33(5): 1195-1199.
	FENG Di, ZHANG Junpeng, SUN Chitao, et al. Responses of cotton growth and water physiological indices to salt stress at different growing stages[J]. Chinese Journal of Ecology, 2014, 33(5): 1195-1199.
[10]	崔永生, 王峰, 孙景生, 等. 南疆机采棉田灌溉制度对土壤水盐变化和棉花产量的影响[J]. 应用生态学报, 2018, 29(11): 3634-3642.
	CUI Yongsheng, WANG Feng, SUN Jingsheng, et al. Effects of irrigation regimes on the variation of soil water and salt and yield of mechanically harvested cotton in Southern Xinjiang, China[J]. Chinese Journal of Applied Ecology, 2018, 29(11): 3634-3642.
[11]	宋喜山, 曹红霞, 何子建, 等. Aquacrop模型在北疆棉花生育期灌溉洗盐制度优化中的适用性[J]. 农业工程学报, 2023, 39(20): 111-122.
	SONG Xishan, CAO Hongxia, HE Zijian, et al. Applicability of the Aquacrop model in optimization of irrigation and salt leaching schedule during the reproductive period of cotton in Northern Xinjiang of China[J]. Transactions of the Chinese Society of Agricultural Engineering, 2023, 39(20): 111-122.
[12]	宰松梅, 仵峰, 范永申, 等. 不同滴灌形式对棉田土壤理化性状的影响[J]. 农业工程学报, 2011, 27(12): 84-89.
	ZAI Songmei, WU Feng, FAN Yongshen, et al. Effects of drip irrigation patterns on soil properties in cotton field[J]. Transactions of the Chinese Society of Agricultural Engineering, 2011, 27(12): 84-89.
[13]	杨劲松, 姚荣江, 王相平, 等. 中国盐渍土研究: 历程、现状与展望[J]. 土壤学报, 2022, 59(1): 10-27.
	YANG Jinsong, YAO Rongjiang, WANG Xiangping, et al. Research on salt-affected soils in China: history, status quo and prospect[J]. Acta Pedologica Sinica, 2022, 59(1): 10-27.
[14]	Vories E, O’Shaughnessy S, Sudduth K, et al. Comparison of precision and conventional irrigation management of cotton and impact of soil texture[J]. Precision Agriculture, 2021, 22(2): 414-431.
[15]	Benouniche M, Errahj M, Kuper M. The seductive power of an innovation: enrolling non-conventional actors in a drip irrigation community in Morocco[J]. The Journal of Agricultural Education and Extension, 2016, 22(1): 61-79.
[16]	Che Z, Wang J, Li J S. Modeling strategies to balance salt leaching and nitrogen loss for drip irrigation with saline water in arid regions[J]. Agricultural Water Management, 2022, 274: 107943.
[17]	Liu X Q, Yan F L, Wu L F, et al. Leaching amount and timing modified the ionic composition of saline-alkaline soil and increased seed cotton yield under mulched drip irrigation[J]. Field Crops Research, 2023, 299: 108988.
[18]	Xiao C, Zhang F C, Li Y, et al. Optimal drip irrigation leaching amount and times enhance seed cotton yield and its stability by improving soil chemical environment and source-sink relationship[J]. Field Crops Research, 2024, 317: 109531.
[19]	Albayrak E, Erensal Y C. Using analytic hierarchy process (AHP) to improve human performance: an application of multiple criteria decision making problem[J]. Journal of Intelligent Manufacturing, 2004, 15(4): 491-503.
[20]	Diakoulaki D, Mavrotas G, Papayannakis L. Determining objective weights in multiple criteria problems: The critic method[J]. Computers & Operations Research, 1995, 22(7): 763-770.
[21]	山成菊, 董增川, 樊孔明, 等. 组合赋权法在河流健康评价权重计算中的应用[J]. 河海大学学报(自然科学版), 2012, 40(6): 622-628.
	SHAN Chengju, DONG Zengchuan, FAN Kongming, et al. Application of combination weighting method to weight calculation in river health evaluation[J]. Journal of Hohai University (Natural Sciences), 2012, 40(6): 622-628.
[22]	张斌, 雍歧东, 肖芳淳. 模糊物元分析[M]. 北京: 石油工业出版社, 1997.
	ZHANG Bin, YONG Qidong, XIAO Fangchung. Fuzzy Object Element Analysis[M]. Beijing: Petroleum Industry Press, 1997.
[23]	衣若晨, 申孝军, 李松敏, 等. 豫北地区冬小麦滴灌灌水技术参数研究[J]. 水土保持学报, 2023, 37(2): 208-216.
	YI Ruochen, SHEN Xiaojun, LI Songmin, et al. Research on drip irrigation technical parameters of winter wheat in northern Henan Province[J]. Journal of Soil and Water Conservation, 2023, 37(2): 208-216.
[24]	崔伟敏, 李明思, 代智光, 等. 滴灌条件下积水区特性的试验研究[J]. 灌溉排水学报, 2010, 29(2): 69-71, 84.
	CUI Weimin, LI Mingsi, DAI Zhiguang, et al. Characteristics of water accumulated areas under drip irrigation[J]. Journal of Irrigation and Drainage, 2010, 29(2): 69-71, 84.
[25]	吴立峰, 张富仓, 周罕觅, 等. 不同滴灌施肥水平对北疆棉花水分利用率和产量的影响[J]. 农业工程学报, 2014, 30(20): 137-146.
	WU Lifeng, ZHANG Fucang, ZHOU Hanmi, et al. Effect of drip irrigation and fertilizer application on water use efficiency and cotton yield in North of Xinjiang[J]. Transactions of the Chinese Society of Agricultural Engineering, 2014, 30(20): 137-146.
[26]	Wang R S, Kang Y H, Wan S Q, et al. Influence of different amounts of irrigation water on salt leaching and cotton growth under drip irrigation in an arid and saline area[J]. Agricultural Water Management, 2012, 110: 109-117.
[27]	张迎春, 张富仓, 范军亮, 等. 滴灌技术参数对南疆棉花生长和土壤水盐的影响[J]. 农业工程学报, 2020, 36(24): 107-117.
	ZHANG Yingchun, ZHANG Fucang, FAN Junliang, et al. Effects of drip irrigation technical parameters on cotton growth, soil moisture and salinity in Southern Xinjiang[J]. Transactions of the Chinese Society of Agricultural Engineering, 2020, 36(24): 107-117.
[28]	苏里坦, 玉米提, 宋郁东. 滴头流量对干旱区膜下滴灌棉田土壤盐分变化的影响[J]. 干旱区地理, 2010, 33(6): 889-895.
	Su litan, Yu miti, SONG Yudong. Effects of emitter discharge rate on soil salt dynamics in cotton field under drip irrigation with mulching condition in arid regions[J]. Arid Land Geography, 2010, 33(6): 889-895.
[29]	杨宗凯, 谭军利, 王西娜, 等. 滴头流量对压砂土壤水盐分布及西瓜生长、产量的影响[J]. 灌溉排水学报, 2023, 42(4): 30-37.
	YANG Zongkai, TAN Junli, WANG Xina, et al. Effect of dripping rate on soil water and salt redistribution and growth and yield of watermelon in gravel-mulched field[J]. Journal of Irrigation and Drainage, 2023, 42(4): 30-37.
[30]	滕安国, 王泽义. 基于博弈论组合确权的模糊物元模型决策膜下滴灌向日葵调亏模式[J]. 灌溉排水学报, 2023, 42(4): 22-29.
	TENG Anguo, WANG Zeyi. Using fuzzy matter-element model and weighted game theory to optimize deficit irrigation scheduling for sunflower[J]. Journal of Irrigation and Drainage, 2023, 42(4): 22-29.

土层深度 Soil depth (cm)	土壤颗粒含量Soil Particle Content(%)			土壤质地 Soil texture	土壤容重 Soil capacity (g/cm³)	田间持水率 Fruit holding rate in field(%)
土层深度 Soil depth (cm)	粘粒 Clay (<0.002 mm)	粉粒 Particle (0.002~0.05 mm)	砂粒 Sand (0.05~2 mm)	土壤质地 Soil texture	土壤容重 Soil capacity (g/cm³)	田间持水率 Fruit holding rate in field(%)
0~20	24.08	32	43.92	壤土	1.51	21.11
20~40	28.08	46	25.92	粘壤土	1.55	24.46
40~60	28.08	58	13.92	粘壤土	1.55	27.57
60~80	42.08	48	9.92	粉(沙)质粘土	1.48	27.24
80~100	52.08	36	11.92	粘土	1.59	23.5

土层深度 Soil depth (cm)	土壤颗粒含量Soil Particle Content(%)			土壤质地 Soil texture	土壤容重 Soil capacity (g/cm³)	田间持水率 Fruit holding rate in field(%)
土层深度 Soil depth (cm)	粘粒 Clay (<0.002 mm)	粉粒 Particle (0.002~0.05 mm)	砂粒 Sand (0.05~2 mm)	土壤质地 Soil texture	土壤容重 Soil capacity (g/cm³)	田间持水率 Fruit holding rate in field(%)
0~20	24.08	32	43.92	壤土	1.51	21.11
20~40	28.08	46	25.92	粘壤土	1.55	24.46
40~60	28.08	58	13.92	粘壤土	1.55	27.57
60~80	42.08	48	9.92	粉(沙)质粘土	1.48	27.24
80~100	52.08	36	11.92	粘土	1.59	23.5

处理 Treat- ments	灌水定额 Irrigation quota (mm)	滴头流量×滴头间距 Dropper flow× Dropper spacing (L/h)(cm)
T₁W₁	52.50	1.4×20
T₂W₁	52.50	2.0×30
T₃W₁	52.50	2.4×30
T₄W₁	52.50	2.7×30
T₁W₂	W₂=γh(S₀-S₁)/K	1.4×20
T₂W₂		2.0×30
T₃W₂		2.4×30
T₄W₂		2.7×30

处理 Treat- ments	灌水定额 Irrigation quota (mm)	滴头流量×滴头间距 Dropper flow× Dropper spacing (L/h)(cm)
T₁W₁	52.50	1.4×20
T₂W₁	52.50	2.0×30
T₃W₁	52.50	2.4×30
T₄W₁	52.50	2.7×30
T₁W₂	W₂=γh(S₀-S₁)/K	1.4×20
T₂W₂		2.0×30
T₃W₂		2.4×30
T₄W₂		2.7×30

生育期 Perild of duration	灌水次数 Irrigation times	灌水时段 Irrigation period (M/D)	W₁ (mm)	W₂ (mm)	灌前平均含盐率 Average salt content before irrgation(%)	脱盐标准 Desalination standard (%)
苗期 Seedling stage	1	6/1~6/2	30.00	83.62	0.48	0.30
苗期 Seedling stage	1	6/17~6/18	52.50	79.93	0.47	0.30
蕾期 Bud stage	2	7/3~7/4	45.00	69.30	0.45	0.30
蕾期 Bud stage	2	7/13~7/14	52.50	60.98	0.43	0.30
花铃期 Flowering and bolling stage	4	7/22~7/24	52.50	82.70	0.48	0.30
		7/31~8/1	52.50	67.91	0.45	0.30
		8/12~8/12	52.50	59.14	0.43	0.30
		8/28~8/29	52.50	59.60	0.43	0.30
合计Total	8	/	412.50	563.18
