Xinjiang Agricultural Sciences ›› 2023, Vol. 60 ›› Issue (9): 2128-2137.DOI: 10.6048/j.issn.1001-4330.2023.09.006
• Crop Genetics and Breeding·Germplasm Resources·Molecular Genetics·Soil Fertilizer • Previous Articles Next Articles
ZHU Yujie1,2(), LIN Ling1,2, TANG Guangmu2, ZHANG Yunshu2, XU Wanli2()
Received:
2022-12-30
Online:
2023-09-20
Published:
2023-09-19
Correspondence author:
XU Wanli (1971-), male, Baoji, Shaanxi, China, researcher, Ph.D., whose research interests are in the field of agricultural and forestry waste resources, soil fertilization and improvement, (E-mail)Supported by:
朱玉洁1,2(), 林玲1,2, 唐光木2, 张云舒2, 徐万里2()
通讯作者:
徐万里 (1971-),男,陕西宝鸡人,研究员,博士,研究方向为农林废弃物资源化、土壤培肥与改良,(E-mail) 作者简介:
朱玉洁(1998 -),女,河南漯河人,硕士研究生,研究方向为农林废弃物资源化,(E-mail)745345099@qq.com
基金资助:
CLC Number:
ZHU Yujie, LIN Ling, TANG Guangmu, ZHANG Yunshu, XU Wanli. Effect of modified cotton straw charcoal on ammonia volatilization characteristics of nitrogen fertilizer in grey desert soils of Xinjiang[J]. Xinjiang Agricultural Sciences, 2023, 60(9): 2128-2137.
朱玉洁, 林玲, 唐光木, 张云舒, 徐万里. 改性棉秆炭对新疆灰漠土氮肥氨挥发特征的影响[J]. 新疆农业科学, 2023, 60(9): 2128-2137.
Add to citation manager EndNote|Ris|BibTeX
URL: http://www.xjnykx.com/EN/10.6048/j.issn.1001-4330.2023.09.006
项目 Itens | pH | 电导率 Condu- ctivity (mS/cm) | 全氮 Total N (g/kg) | 碱解氮 Alkaline N (mg/kg) | 全磷 Total P (g/kg) | 速效磷 Avaliable P (mg/kg) | 全钾 Total K (g/kg) | 速效钾 Avaliable P (mg/kg) | 有机碳 Organic carbon (g/kg) |
---|---|---|---|---|---|---|---|---|---|
灰漠土 Gray desert soil | 8.27 | 0.36 | 0.33 | 28.00 | 0.99 | 39.10 | 26.15 | 0.57 | 4.49 |
棉秆炭 Cotton straw charcoal | 10.17 | 3.46 | 1.90 | 153.20 | 0.29 | 0.82 | 2.36 | - | - |
味精废液改性炭 Monosodium glutamate waste liquid modified carbon | 4.67 | 3.89 | 4.13 | - | 0.22 | 2.25 | 1.84 | - | - |
木醋液改性炭 Wood vinegar modified carbon | 8.37 | 1.77 | 0.94 | 113.40 | 0.82 | 3.07 | 2.35 | - | - |
酒石酸改性炭 Tartric acid modified carbon | 4.84 | 0.44 | 2.04 | - | 0.53 | 1.03 | 0.36 | - | - |
Tab.1 Nutrient contents and physicochemical properties of cotton stalk charcoal and soil
项目 Itens | pH | 电导率 Condu- ctivity (mS/cm) | 全氮 Total N (g/kg) | 碱解氮 Alkaline N (mg/kg) | 全磷 Total P (g/kg) | 速效磷 Avaliable P (mg/kg) | 全钾 Total K (g/kg) | 速效钾 Avaliable P (mg/kg) | 有机碳 Organic carbon (g/kg) |
---|---|---|---|---|---|---|---|---|---|
灰漠土 Gray desert soil | 8.27 | 0.36 | 0.33 | 28.00 | 0.99 | 39.10 | 26.15 | 0.57 | 4.49 |
棉秆炭 Cotton straw charcoal | 10.17 | 3.46 | 1.90 | 153.20 | 0.29 | 0.82 | 2.36 | - | - |
味精废液改性炭 Monosodium glutamate waste liquid modified carbon | 4.67 | 3.89 | 4.13 | - | 0.22 | 2.25 | 1.84 | - | - |
木醋液改性炭 Wood vinegar modified carbon | 8.37 | 1.77 | 0.94 | 113.40 | 0.82 | 3.07 | 2.35 | - | - |
酒石酸改性炭 Tartric acid modified carbon | 4.84 | 0.44 | 2.04 | - | 0.53 | 1.03 | 0.36 | - | - |
氨挥发总量 Total ammonia volatilization | pH | 电导率 Conductivity | 全氮含量 Total nitrogen content | 有机碳含量 Organic carbon content | |
---|---|---|---|---|---|
氨挥发总量 Total ammonia volatilization | 1 | ||||
pH | -0.631* | 1 | |||
电导率 Conductivity | 0.708** | -0.892** | 1 | ||
全氮含量 Total nitrogen content | 0.640* | -0.716** | 0.843** | 1 | |
有机碳含量 Organic carbon content | 0.024 | -0.222 | 0.044 | 0.09 | 1 |
Tab.2 Correlation between pH, electrical conductivity, total nitrogen content, organic carbon and total ammonia volatilization in soil after application of modified cottonstalk carbon
氨挥发总量 Total ammonia volatilization | pH | 电导率 Conductivity | 全氮含量 Total nitrogen content | 有机碳含量 Organic carbon content | |
---|---|---|---|---|---|
氨挥发总量 Total ammonia volatilization | 1 | ||||
pH | -0.631* | 1 | |||
电导率 Conductivity | 0.708** | -0.892** | 1 | ||
全氮含量 Total nitrogen content | 0.640* | -0.716** | 0.843** | 1 | |
有机碳含量 Organic carbon content | 0.024 | -0.222 | 0.044 | 0.09 | 1 |
[1] | 魏诗雯. 提升我国棉花竞争力势在必行[N]. 中国纺织报, 2022-04-25( 002). |
WEI Shiwen. Imperative to improve China's cotton competitiveness[N]. China Textile News, 2022-04-25( 002). | |
[2] | 李一, 王秋兵. 我国秸秆资源养分还田利用潜力及技术分析[J]. 中国土壤与肥料, 2020,(1):119-126. |
LI Yi, WANG Qiubing. Potential and technical analysis of nutrient returning from straw resources in China[J]. Soil and Fertilizer Science in China, 2020,(1):119-126. | |
[3] | 杜为研, 唐杉, 汪洪. 我国有机肥资源及产业发展现状[J]. 中国土壤与肥料, 2020,(3): 210-219. |
DU Weiyan, TANG Shan, WANG Hong. Development status of Organic Fertilizer Resources and Industry in China[J]. China Soil and Fertilizer, 2020,(3): 210-219. | |
[4] |
侯艳艳, 朱新萍, 徐万里, 等. 施用生物炭对灰漠土养分及棉花生长的影响[J]. 新疆农业科学, 2018, 55(1): 24-32.
DOI |
HOU Yanyan, ZHU Xinping, XU Wanli, et al. Effects of biochar application on soil nutrients and cotton growth[J]. Xinjiang Agricultural Sciences, 2018, 55(1): 24-32.
DOI |
|
[5] | 顾美英, 杨蓉, 徐万里, 等. 棉秆炭配施生物有机肥对连作棉花根际土壤微生态和棉花生长的影响[J]. 中国农业科技导报, 2019, 21(146): 47-57. |
GU Meiying, YANG Rong, XU Wanli, et al. Effects of bioorganic fertilizer application on rhizosphere soil microecology and cotton growth in continuous cropping cotton[J]. Review of China Agricultural Science and Technology, 2019, 21(146): 47-57. | |
[6] | 黄雁飞, 陈桂芬, 熊柳梅, 等. 不同秸秆生物炭对水稻生长及土壤养分的影响[J]. 南方农业学报, 2020, 51(9): 2113-2119. |
HUANG Yanfei, CHEN Guifen, XIONG Liumei, et al. Effects of different straw biochar on rice growth and soil nutrients[J]. Journal of Southern Agriculture, 2020, 51(9): 2113-2119. | |
[7] |
Zhang X, Huang R, Cao Y, et al. Rapid conversion of red mud into soil matrix by co-hydrothermal carbonization with biomass wastes[J]. Journal of Environmental Chemical Engineering, 2021, 9(5), 106039.
DOI URL |
[8] | 宋延静, 龚骏. 施用生物质炭对土壤生态系统功能的影响[J]. 鲁东大学学报(自然科学版), 2010, 26(4): 361-365. |
SONG Yanjing, GONG Jun. Effects of biochar application on soil ecosystem function[J]. Journal of Ludong University (Natural Science Ed.), 2010, 26(4): 361-365. | |
[9] | 崔雨桐. 秸秆生物炭对苏打盐碱土磷素组分及改良效果影响[D]. 哈尔滨: 东北农业大学, 2021. |
CUI Yutong. Effects of straw biochar on phosphorus composition and improvement of soda saline-alkali soil[D]. Harbin: Northeast Agricultural University, 2021. | |
[10] | 李琦, 廖娜, 张妮, 等. 棉花秸秆及其生物炭对滴灌棉田氨挥发的影响[J]. 农业环境科学学报, 2014, 33(10):1987-1994. |
LI Qi, LIAO Na, ZHANG Ni, et al. Effects of cotton straw and biochar on ammonia volatilization in drip irrigation cotton field[J]. Journal of Agro-Environment Science, 2014, 33(10):1987-1994. | |
[11] | 秦蓓. 棉秆炭对新疆灌耕灰漠土和风沙土pH值及氨挥发的影响[D]. 乌鲁木齐: 新疆农业大学, 2018. |
QIN Bei. Effects of cotton stalk carbon on pH value and ammonia volatilization in grey desert soil and aeolian sandy soil under irrigation in Xinjiang[D]. Urumqi: Xinjiang Agricultural University, 2018. | |
[12] | Zhang X, Wu Y, Liu X, et al. Ammonia Emissions May Be Substantially Underestimated in China[J]. Environmental Science & Technology: ES&T, 2017, 51(21):12089-12096. |
[13] |
Zhang M, Song G, Gelardi D L, et al. Evaluating biochar and its modifications for the removal of ammonium,nitrate,and phosphate in water[J]. Water Research, 2020, 186(Nov.1):116303.
DOI URL |
[14] |
Sajjadi B, Chen W, Egiebor N. A comprehensive review on physical activation of biochar for energy and environmental applications[J]. Reviews in Chemical Engineering, 2019, 35(6): 735-776.
DOI URL |
[15] | Sza B, Xin W, Zhen C E, et al. Modified cornstalk biochar can reduce ammonia emissions from compost by increasing the number of ammonia-oxidizing bacteria and decreasing urease activity[J]. Bioresource Technology, 2021, 319. |
[16] | 魏存, 吕豪豪, 汪玉瑛, 等. 铁改性稻壳生物炭对铵态氮的吸附效果研究[J]. 植物营养与肥料学报, 2021, 27(4):595-609. |
WEI Cun, LYU Haohao, WANG Yuying, et al. Effect of iron modified rice husk biochar on ammonium nitrogen adsorption[J]. Plant Nutrition and Fertilizer Science, 2021, 27(4):595-609. | |
[17] | 申书伟, 张丹丹, 王敏鸽, 等. 木醋液酸化生物炭与氮素配施对盐渍土壤活性氮及氨挥发的影响[J]. 环境科学, 2022, 43(5):2779-2787. |
SHEN Shuwei, ZHANG Dandan, WANG Minge, et al. Effects of wood vinegar acidified biochar and nitrogen application on active nitrogen and ammonia volatilization in saline soil[J]. Environmental Science, 2022, 43(5):2779-2787. | |
[18] |
Lu C, Qincheng C, Pinhua R, et al. Formulating and optimizing anovel biochar-based fertilizer for simultaneous slow-release of nitrogen and immobiliza-tion of cadmium[J]. Sustainability, 2018, 10(8), 2740.
DOI URL |
[19] | Puga A P, Queiroz M C D A, Ligo M A V, et al. Nitrogen availability and ammonia volatilization in biochar-based fertilizers[J]. Archives of Agronomy and Soil Science, 2019, 08(66). |
[20] |
Liu X, Liao J, Song H, et al. A Biochar-Based Route for Environmentally Friendly Controlled Release of Nitrogen: Urea-Loaded Biochar and Bentonite Composite,[J]. Scientific Reports, 2019, 9 (2): 9548.
DOI |
[21] | 柳萌, 何斌, 赵鹏, 等. 生物炭吸附聚谷氨酸对豫南酸性农田作物生长的影响[J]. 河南农业大学学报, 2021, 55(6):1134-1141. |
LIU Meng, HE Bin, ZHAO Peng, et al. Effects of polyglutamic acid adsorption on crop growth in acidic cropland of southern Henan[J]. Journal of Henan Agricultural University, 2021, 55(6):1134-1141. | |
[22] |
Sun L, Chen D, Wan S, et al. Performance, kinetics, and equilibrium of methylene blue adsorption on biochar derived from eucalyptus saw dust modified with citric, tartaric, and acetic acids[J]. Bioresource Technology, 2015, 198 : 300-308.
DOI PMID |
[23] |
Wong K K, Lee C K, Low K S, et al. Removal of Cu and Pb from electroplating wastewater using tartaric acid modified rice husk[J]. Process Biochemistry, 2003, 39(4): 437-445.
DOI URL |
[24] | 鲍士旦. 土壤农化分析[M]. 北京: 中国农业出版社, 1999. |
BAO Shidan. Soil Agrochemical Analysis[M]. Beijing: China Agriculture Press, 1999. | |
[25] |
Mandal S, Thangarajan R, Bolan N S, et al. Biochar-induced concomitant decrease in ammonia volatilization and increase in nitrogen use efficiency by wheat[J]. Chemosphere: Environmental Toxicology and Risk Assessment, 2016, 142:120-127.
DOI PMID |
[26] |
许云翔, 何莉莉, 陈金媛, 等. 生物炭对农田土壤氨挥发的影响机制研究进展[J]. 应用生态学报, 2020, 31(12):4312-4320.
DOI |
XU Yunxiang, HE Lili, CHEN Jinyuan, et al. Effects of biochar on ammonia volatilization in soil[J]. Chinese journal of Applied Ecology, 2020, 31(12):4312-4320.
DOI |
|
[27] |
Sha Z P, Li Q Q, Lv T, et al. Response of ammoniavolatilization to biochar addition:A meta-analysis[J]. Science of the Total Environment, 2018, 655: 1387-1396.
DOI URL |
[28] |
Asada T, Ishihara S, Yamane T, et al. Science of Bamboo Charcoal: Study on Carbonizing Temperature of Bamboo Charcoal and Removal Capability of Harmful Gases[J]. Journal of Health Science, 2002, 48(6):473-479.
DOI URL |
[29] | Lehmann J, Gaunt J, Rondon M. Biochar sequestration in terrestrial ecosystems:A review[J]. Mitigation and Adaptation Strategies for GlobalChance, 2006, 11(2): 395-419. |
[30] |
Arezoo Taghizadeh-Toosi, Clough T J, Condron L M, et al. Biochar incorporation into pasture soil suppresses in situ nitrous oxide emissions from ruminant urine patches[J]. Journal of Environmental Quality, 2011, 40(2) : 468.
DOI URL |
[31] | 南京土壤所在盐渍化农田改良剂应用对氨挥发影响研究中取得进展[J]. 粮油与饲料科技, 2020,(3):48. |
Unknown author. The Nanjing Soil Institute has made progress in the study of the effect of salinized farmland improver on ammonia volatilization[J]. Grain, Oil and Feed Science and Technology, 2020,(3): 48. | |
[32] |
Sun L, Li L, Chen Z, et al. Combined effects of nitrogen deposition and biochar application on emissions of N2O, CO2 and NH3 from agricultural and forest soils[J]. Soil Science and Plant Nutrition, 2014, 60(2):254-265.
DOI URL |
[33] |
Feng Y, Sun H, Xue L, et al. Biochar applied at an appropriate rate can avoid increasing NH3 volatilization dramatically in rice paddy soil[J]. Chemosphere, 2017, 168:1277-1284.
DOI URL |
[34] |
Sun H, Lu H, Chu L, et al. Biochar applied with appropriate rates can reduce N leaching, keep N retention and not increase NH3 volatilization in a coastal saline soil[J]. Science of the Total Environment, 2017, 575:820-825.
DOI URL |
[35] | 梁飞, 田长彦. 土壤盐渍化对尿素与磷酸脲氨挥发的影响[J]. 生态学报, 2011, 31(14):3999-4006. |
LIANG Fei, TIAN Changyan. Effects of soil salinization on volatilization of urea and urea-ammonia phosphate[J]. Acta Ecologica Sinica, 2011, 31(14): 3999-4006. | |
[36] |
Sun J, Fan Q, Ma J, et al. Effects of biochar on cadmium (Cd) uptake in vegetables and its natural downward movement in saline-alkali soil[J]. Environmental Pollutants and Bioavailability, 2020, 32(1): 36-46.
DOI URL |
[37] | He K, Guo H, Wang C P, et al. Biochar amendment ameliorates soil properties and promotes Miscanthus growth in a coastal saline-alkali soil[J]. Applied Soil Ecology, 2020, 155. |
[38] |
顾美英, 刘洪亮, 李志强, 等. 新疆连作棉田施用生物炭对土壤养分及微生物群落多样性的影响[J]. 中国农业科学, 2014, 47(20) : 4128-4138.
DOI |
GU Meiying, LIU Hongliang, LI Zhiqiang, et al. Effects of biochar application on soil nutrients and microbial community diversity in continuous cropping cotton field in Xinjiang[J]. Scientia Agricultura Sinica, 2014, 47(20): 4128-4138.
DOI |
|
[39] | 唐光木, 葛春晖, 徐万里, 等. 施用生物黑炭对新疆灰漠土肥力及玉米生长的影响[J]. 农业环境科学学报, 2011, 30(9): 1797-1 802. |
TANG Guangmu, GE Chunhui, XU Wanli, et al. Effects of biochar application on soil fertility and maize growth in Xinjiang Grey desert[J]. Journal of Agro-Environment Science, 2011, 30(9) : 1797-1,802. | |
[40] | Zhu H, Yang J, Yao R, et al. Interactive effects of soil amendments (biochar and gypsum) and salinity on ammonia volatilization in coastal saline soil[J]. Catena, 2020, 190. |
[41] | 吴丹, 孙萍, 路鹏展, 等. 浒苔生物炭对滨海盐碱土壤改良的效果及途径[J]. 环境科学, 2020, 41(4):1941-1949. |
WU Dan, SUN Ping, LU Pengzhan, et al. Effects and approaches of Entermorpha prolifera biochar on coastal saline-alkali soil improvement[J]. Environmental Science, 2020, 41(4) : 1941-1949. | |
[42] |
Wang Z, Yin D, Wang H, et al. Effects of biochar on waterlogging and the associated change in micro-ecological environment of maize rhizosphere soil in saline-alkali land[J]. Bioresources, 2020, 15(4):9303-9323.
DOI URL |
