Optimization of high-efficiency decomposition conditions and transformation parameters of grapevine branches eaten by the Protaetia brevitarsis Lewis

doi:10.6048/j.issn.1001-4330.2024.12.022

Abstract

Abstract:

【Objective】 Optimization of high-efficiency decomposition conditions and transformation parameters of grapevine branches eaten by the Protaetia brevitarsis Lewis,which has provided a new way for the resource utilization of grape branches.【Methods】 Crushed grape branches were taken as the main raw materials, the orthogonal experiment of 3 factors and 5 levels was performed, which included the decomposition inoculants, the ratio of cow dung (%) and the number of fermentation days (d).By measuring the conversion power of larvae to the materials, the optimal combination of feeding grape branches by the larva was screened and verified.【Results】 The results showed that the proportion of cow dung reached a significant difference level at the 10 th, 15 th, 25 th and 30 th days.The higher the proportion of cow dung, the higher the temperature, indicating the better fermentation rate, and the addition of decomposition inoculants and cow dung had a better promotion effect on the fermentation of materials.After fermentation for 25 days, 96 g of compound feed was obtained from each 120 g of raw grape branches, supplemented with 80g of cow dung and 1‰ VT decomposition inoculants.After the conversion of the 3rd larva, the insect sand content was (77.53±22.43)g, the insect body conversion rate was (37.16%±0.04%), and the insect sand conversion rate was (84.99%±0.01%).The harvest coefficient of insect sand was (59.47%±0.04%), and the utilization rate of organic materials was (61.17%±0.02%).【Conclusion】 The 3rd instar larvae of the Protaetia brevitars has a good conversion ability to ferment grape branch feed.Adding 1%VT decomposition inoculants, 40% cow dung and after 25 d fermentation is the best fermentation scheme.

Key words: grape branches; larvae of Protaetia brevitarsis Lewis; decomposing inoculants; biotransformation; resource utilization

摘要：

【目的】 研究白星花金龟取食葡萄枝条的高效腐解条件和转化参数优化,为葡萄枝条的资源化利用提供新路径。【方法】 以粉碎的葡萄枝条为主要原料,开展腐解菌剂、牛粪配比(%)和酵化天数(d)的3因素5水平正交试验,测定幼虫对物料的转化力,筛选并验证白星花金龟幼虫取食葡萄枝条的最优组合。【结果】 牛粪配比在第10、15、25和30 d达到显著差异水平,牛粪配比越高,其温度越高,酵化速度越好,添加菌剂和牛粪对物料的酵化有较好的促进作用;每120 g的葡萄枝条原料,辅加80 g的牛粪,添加1‰VT菌剂,发酵25 d后,获得配合饲料96 g,经白星花金龟3龄幼虫转化后,虫砂量为(77.53±22.43) g,虫体转化率(37.16%±0.04%),虫砂转化率为(84.99%±0.01%),虫砂收获系数(59.47%±0.04%),有机物料利用率在(61.17%±0.02%)。【结论】 白星花金龟3龄幼虫对发酵葡萄枝条饲料具有较好的转化力,添加1%VT菌剂、40%牛粪,酵化25 d为最佳酵化方案。

关键词: 葡萄枝条, 白星花金龟幼虫, 腐解菌剂, 生物转化, 资源化利用

CLC Number:

S432

XU Andong, ZHANG Guangjie, FU Rao, MENG Zhuo, YAN Yu, LI Baoguo, MA Deying. Optimization of high-efficiency decomposition conditions and transformation parameters of grapevine branches eaten by the Protaetia brevitarsis Lewis[J]. Xinjiang Agricultural Sciences, 2024, 61(12): 3067-3077.

徐安东, 张广杰, 付娆, 孟卓, 颜宇, 李保国, 马德英. 白星花金龟取食葡萄枝条的高效腐解条件和转化参数优化[J]. 新疆农业科学, 2024, 61(12): 3067-3077.

Figures/Tables 16

References 26

[1]	满保德. 新疆吐鲁番地区葡萄产业发展对策研究[D]. 石河子: 石河子大学, 2017.
	MAN Baode. Research on the development strategy of grape industry in Turpan, Xinjiang[D]. Shihezi: Shihezi University, 2017.
[2]	雷天翔, 施维新, 宋敏, 等. 新疆生产建设兵团葡萄产业发展问题与对策[J]. 中国果树, 2023,(9): 117-121.
	LEI Tianxiang, SHI Weixin, SONG Min, et al. Problems and countermeasures for the development of grape industry in Xinjiang Production and Construction Corps[J]. China Fruits, 2023,(9): 117-121.
[3]	杨明昊, 张艺灿, 王孝娣, 等. 葡萄枝条堆肥对设施栽培葡萄园土壤和87-1葡萄生长发育的影响[J]. 中国果树, 2023(4): 78-81, 86.
	YANG Minghao, ZHANG Yican, WANG Xiaodi, et al. Effects of grape branch compost on soil and ‘87-1’ grape growth in protected cultivation vineyard[J]. China Fruits, 2023(4): 78-81, 86.
[4]	刘文政, 平凤姣, 白雪冰, 等. 葡萄枝条资源化利用研究现状及进展[J]. 农业工程学报, 2022, 38(16): 270-283.
	LIU Wenzheng, PING Fengjiao, BAI Xuebing, et al. Status and prospect of resource utilization for grape vine stalks[J]. Transactions of the Chinese Society of Agricultural Engineering, 2022, 38(16): 270-283.
[5]	张广杰. 虫菌复合技术转化棉秆还田对棉花生长发育及黄萎病发生的影响[D]. 乌鲁木齐: 新疆农业大学, 2022.
	ZHANG Guangjie. Effects of conversion of cotton stalk to field by insect-bacteria composite Technology on cotton growth and development and occurrence of verticillium wilt[D] Urumqi: Xinjiang Agricultural University, 2022.
[6]	刘玉升, 骆洪义, 叶保华. 餐厨废弃物的环境昆虫处理途径及资源化利用探讨[J]. 再生资源与循环经济, 2013, 6(4): 35-37.
	LIU Yusheng, LUO Hongyi, YE Baohua. The treatment and utilization approach of kitchen waste by environmental insects[J]. Recyclable Resources and Circular Economy, 2013, 6(4): 35-37.
[7]	周婷, 赵威, 赵传岳, 等. 灵芝菌糠对白星花金龟幼虫生长性能的影响[J]. 山东农业大学学报(自然科学版), 2022, 53(6): 868-873.
	ZHOU Ting, ZHAO Wei, ZHAO Chuanyue, et al. Effects of the spent substrate of ganodorma lucidum on the growth performance of Protaetia brevitarsis lewis larvae[J]. Journal of Shandong Agricultural University (Natural Science Edition), 2022, 53(6): 868-873.
[8]	张广杰. 白星花金龟对有机废弃物的转化技术研究[D]. 泰安: 山东农业大学, 2019.
	ZHANG Guangjie. Research on the conversion technology of organic waste by Protaetia brevitarsis[D]. Taian: Shandong Agricultural University, 2019.
[9]	张广杰, 王倩, 刘玉升. 白星花金龟人为条件生物学与应用潜力[J]. 环境昆虫学报, 2020, 42(2): 257-266.
	ZHANG Guangjie, WANG Qian, LIU Yusheng. Biology under artificial condition and utilization potential of Potosia brevitarsis (Coleoptera: Cetoniidea)[J]. Journal of Environmental Entomology, 2020, 42(2): 257-266.
[10]	秦铭潞. 白星花金龟幼虫蛋白的提取、分离纯化及抗炎性研究[D]. 泰安: 山东农业大学, 2020.
	QIN Minglu. Study on extraction, isolation and purification of protein from larva of the Protaetia brevitarsis and its anti-inflammatory[D]. Taian: Shandong Agricultural University, 2020.
[11]	史长旭, 张广杰, 徐业山, 等. 白星花金龟虫粪砂混配基质对黄瓜和辣椒育苗效果的影响[J]. 新疆农业大学学报, 2021, 44(6): 443-447.
	SHI Changxu, ZHANG Guangjie, XU Yeshan, et al. Effects of Protaetia brevitarsis lewis larvae dung-sand mixture matrix on cucumber and pepper seedling[J]. Journal of Xinjiang Agricultural University, 2021, 44(6): 443-447.
[12]	Yoon H S, Lee C S, Lee S Y, et al. Purification and cDNA cloning of inducible antibacterial peptides from Protaetia brevitarsis (Coleoptera)[J]. Archives of Insect Biochemistry and Physiology, 2003, 52(2): 92-103. PMID
[13]	Lee D G, Park J H, Shin S Y, et al. Design of novel analogue peptides with potent fungicidal but low hemolytic activity based on the cecropin A-melittin hybrid structure[J]. Biochemistry and Molecular Biology International, 1997, 43(3): 489-498. PMID
[14]	杨诚, 刘玉升, 徐晓燕, 等. 白星花金龟幼虫资源成分分析及评价[J]. 山东农业大学学报(自然科学版), 2014, 45(2): 166-170.
	YANG Cheng, LIU Yusheng, XU Xiaoyan, et al. Analysis and evaluation of resource components of Protaetia brevitarsis(lewis) larvae[J]. Journal of Shandong Agricultural University (Natural Science Edition), 2014, 45(2): 166-170.
[15]	Li Y M, Fu T, Geng L L, et al. Protaetia brevitarsis larvae can efficiently convert herbaceous and ligneous plant residues to humic acids[J]. Waste Management, 2019, 83: 79-82. DOI PMID
[16]	Manning P, Slade E M, Beynon S A, et al. Functionally rich dung beetle assemblages are required to provide multiple ecosystem services[J]. Agriculture, Ecosystems & Environment, 2016, 218: 87-94.
[17]	刘玉升, 张大鹏. 基于白星花金龟幼虫转化玉米秸秆的微循环农牧场模式研究[J]. 安徽农业科学, 2015, 43(31): 85-87.
	LIU Yusheng, ZHANG Dapeng. Study on the model of microcirculation farm and ranch on the corn straw transformed by larval of Potosia brevitarsis lewis[J]. Journal of Anhui Agricultural Sciences, 2015, 43(31): 85-87.
[18]	Zhang G J, Xu Y S, Zhang S, et al. Transformation capability optimization and product application potential of proteatia brevitarsis (Coleoptera: Cetoniidae) larvae on cotton stalks[J]. Insects, 2022, 13(12): 1083.
[19]	何笙, 周泽容, 吴赵平, 等. 白星花金龟发生与防治技术研究初报[J]. 中国农学通报, 2006, 22(6): 314-316.
	HE Sheng, ZHOU Zerong, WU Zhaoping, et al. A study on the occurrence of postosia brevitarsis leiwis and its prevention & control technology[J]. Chinese Agricultural Science Bulletin, 2006, 22(6): 314-316. DOI
[20]	王佳男. 基于白星花金龟幼虫活体筛选高致病力白僵菌菌株[D]. 泰安: 山东农业大学, 2019.
	WANG Jianan. Screening of high-virulence strains of Beauveria bassiana based on Protaetia brevitarsis larvae[D]. Taian: Shandong Agricultural University, 2019.
[21]	郭勇. 郓城县农业有机废弃物资源调查和环保昆虫转化处理模式探究[D]. 泰安: 山东农业大学, 2020.
	GUO Yong. Yuncheng County Investigation of agricultural organic waste resour-ces and exploration of Environmental protection insect transformation treatment model[D]. Taian: Shandong Agricultural University, 2020.
[22]	张倩. 取食平菇菌糠的白星花金龟生物学研究[D]. 泰安: 山东农业大学, 2015.
	ZHANG Qian. Biological study of Protaetia brevitarsis feeding on oyster mush-room bran[D]. Taian: Shandong Agricultural University, 2015.
[23]	孙晨可. “小麦秸秆—大球盖菇—白星花金龟” 循环模式研究[D]. 泰安: 山东农业大学, 2018.
	SUN Chenke. Study on the cycle pattern of "wheat straw - large ball mushroom - Protaetia brevitarsis"[D]. Taian: Shandong Agricultural University, 2018.
[24]	Gossner M M, Lachat T, Brunet J, et al. Current near-to-nature forest management effects on functional trait composition of saproxylic beetles in beech forests[J]. Conservation Biology, 2013, 27(3): 605-614. DOI PMID
[25]	Zhang X F, Wang L Y, Liu C Q, et al. Identification and field verification of an aggregation pheromone from the white-spotted flower chafer, Protaetia brevitarsis lewis (Coleoptera: Scarabaeidae)[J]. Scientific Reports, 2021, 11(1): 22362.
[26]	徐业山. 虫菌复合技术分离棉田残膜回收混合物研究[D]. 乌鲁木齐: 新疆农业大学, 2022.
	XU Yeshan. Study on separation of residue film recovery mixture from cotton field by insect-bacteria composite technology[D]. Urumqi: Xinjiang Agricultural University, 2022.

腐解菌剂 Decomposition inoculant	主要功能菌 Main functional bacteria	有效活菌数 Effective number ofviable bacteria (100 million/g)	推荐用量 Recomm ended dosage (kg/t)
RW特配型 (鹤壁人元)	细菌(枯草、地衣、胶冻)、丝状菌和酵母菌	100	10
VT-1000 (北京沃土)	芽孢、放线、乳酸和霉菌	200	1
LK (中农绿康)	芽孢、木霉和酵母	8	0.5
LL(山东绿陇)	枯草/地衣芽孢杆菌, 酵母、绿色木霉	200	10
EM(日本)	酵母菌、乳酸菌	100	10

腐解菌剂 Decomposition inoculant	主要功能菌 Main functional bacteria	有效活菌数 Effective number ofviable bacteria (100 million/g)	推荐用量 Recomm ended dosage (kg/t)
RW特配型 (鹤壁人元)	细菌(枯草、地衣、胶冻)、丝状菌和酵母菌	100	10
VT-1000 (北京沃土)	芽孢、放线、乳酸和霉菌	200	1
LK (中农绿康)	芽孢、木霉和酵母	8	0.5
LL(山东绿陇)	枯草/地衣芽孢杆菌, 酵母、绿色木霉	200	10
EM(日本)	酵母菌、乳酸菌	100	10

水平 Levels	因素Factors
水平 Levels	腐解菌剂 Decomposition inoculants	牛粪配比 Manure proportion (%)	酵化天数 Fermentation days (d)
1	RW	10	10
2	VT	20	15
3	LK	30	20
4	LL	40	25
5	EM	50	30

水平 Levels	因素Factors
水平 Levels	腐解菌剂 Decomposition inoculants	牛粪配比 Manure proportion (%)	酵化天数 Fermentation days (d)
1	RW	10	10
2	VT	20	15
3	LK	30	20
4	LL	40	25
5	EM	50	30

处理 Treatments	因素Factors
处理 Treatments	腐解菌剂 Decomposition inoculants	牛粪配比 Manure proportion (%)	酵化天数 Fermentation days (d)
CK	0	0	0
CK₁	0	0	10
CK₂	0	0	15
CK₃	0	0	20
CK₄	0	0	25
CK₅	0	0	30
