Analysis of reference crop evapotranspiration and characteristics of irrigation water requirement of different crops

doi:10.6048/j.issn.1001-4330.2024.07.010

Abstract

Abstract:

【Objective】The reference crop evapotranspiration combined with crop coefficient can be used to estimate the irrigation water requirement at each growth stage of crops, which might provide a basis for agricultural water allocation.【Methods】In this paper, the reference crop evapotranspiration (ET₀) was simulated by Hargreaves-Samani (H-S), Irmark-Allen (I-A) and Priestley-Taylor (P-T) methods in Aksu city of Xinjiang. The precision of the three simulation methods was evaluated according to R², nRMSE and MAPE, and the variation of ET₀ at interannual and monthly scales was analyzed. Different typical years were selected to analyze the water demand rules of winter wheat, cotton, spring maize and summer maize.【Results】(1) The R² of ET₀ calculated by Hargreaves-Samani method, Irmark-Allen method and Priestley-Taylor method were 0. 965, 0. 949 and 0. 946, respectively, and MAPE were 20. 85 %, 26. 46 % and 66. 71 %, respectively. (2) The 30-year average cumulative value of ET₀ in the study region was 960 mm, which was larger from May to August and smaller in December and January. (3) The irrigation water requirements of winter wheat, cotton, spring corn and summer corn were 108 mm, 308 mm, 131 mm and 136 mm respectively in the regreening-jointing stage, flowering-budding stage, heading-milk stage and heading-milk stage. (4) During the whole growth period, the water requirements of winter wheat, cotton, spring corn and summer corn were 448, 533, 394 and 385 mm, respectively.【Conclusion】H-S method and I-A method has good universality in Aksu city; the cumulative value of ET₀ in the study region did not change much between years, and it increased first and then decreased during the year; the key water requirement periods of winter wheat cotton, spring corn and summer corn were reviving-jointing stage, flowering-flocculation stage, heading-milk ripening stage and heading-milk ripening stage, respectively; during the whole growth period, the water requirement of cotton is the largest, followed by winter wheat, spring corn and summer corn.

Key words: reference crop evapotranspiration; Hargreaves-Samani method; Irmark-Allen method; Priestley-Taylor method; irrigation water requirement

摘要：

【目的】研究分析参考作物蒸散量结合作物系数估算作物各生育阶段灌溉需水量特征,为农业用水调配提供依据。【方法】基于新疆阿克苏市气象站点1980~2010年逐日气象数据,采用Hargreaves-Samani(H-S)、Irmark-Allen(I-A)和Priestley-Taylor(P-T)3种方法模拟计算参考作物蒸散量(Reference Crop Evapotranspiration,ET₀),依据R²、nRMSE和MAPE评价3种模拟方法的精度,并分析ET₀在年际间和月尺度下的变化规律。分析不同典型年冬小麦、棉花、春玉米、夏玉米的需水规律。【结果】(1) H-S法、I-A法和P-T法计算的研究区ET₀模拟值与标准值的R²分别为0.965、0.949、0.946,MAPE分别为20.85%、26.46%、66.71%。(2) 研究区全年ET₀累计值30年均值为960 mm,5~8月较大,12月和1月较小。(3) 冬小麦、棉花、春玉米、夏玉米分别在返青-拔节期、开花-吐絮期、抽穗-乳熟期、抽穗-乳熟期的灌溉需水量最大,其对应值为108、308、131和136 mm。(4) 全生育期内,冬小麦、棉花、春玉米、夏玉米的灌溉需水量分别为448、533、394和385 mm。【结论】H-S法和I-A法在新疆阿克苏市ET₀计算有良好的普适性;研究区ET₀累计值年际间变化不大,年内呈先增大再减小的趋势;冬小麦、棉花、春玉米、夏玉米的关键需水期分别为返青-拔节期、开花-吐絮期、抽穗-乳熟期、抽穗-乳熟期;全生育期内,棉花灌溉需水量最大,其次为冬小麦、春玉米、夏玉米。

关键词: 参考作物蒸散量, Hargreaves-Samani法, Irmark-Allen法, Priestley-Taylor法, 灌溉需水量

CLC Number:

S275.3

ZHANG Ni, ZHENG Zhiwei, DOU Jingjing, WANG Yikun, ZHANG Yanfen, LIU Chunlai. Analysis of reference crop evapotranspiration and characteristics of irrigation water requirement of different crops[J]. Xinjiang Agricultural Sciences, 2024, 61(7): 1640-1647.

张妮, 郑志伟, 豆静静, 王义坤, 张艳芬, 刘春来. 参考作物蒸散量的计算及不同作物灌溉需水量的特征分析[J]. 新疆农业科学, 2024, 61(7): 1640-1647.

Figures/Tables 6

References 29

[1]	张卫东, 纵华, 秦勇. 阿克苏地区粮食产业可持续发展战略研究[J]. 新疆农业科学, 2007, 44(S2): 272-275.
	ZHANG Weidong, ZONG Hua, QIN Yong. Study on sustainable development strategy of grain industry in Aksu Region[J]. Xinjiang Agricultural Sciences, 2007, 44(S2): 272-275.
[2]	刘栩辰, 马守田, 黄超, 等. 黄淮海平原夏玉米需水量和缺水量时空分布特征[J]. 水土保持学报, 2023, 37(2):179-186.
	LlU Xuchen, MA Shoutian, HUANG Chao, et al. Temporal Distribution of Water Requirement and Water Deficiency of summer Maize in Huang-Huai-Hai Plain[J]. Journal of Soil and Water Conservation, 2023, 37(2):179-186.
[3]	代丽娟. 阿克苏地区水环境质量改善居民支付意愿及影响因素研究[D]. 阿拉尔: 塔里木大学, 2022.
	DAI Lijuan. Study on the payment willingness and influencing factors of water environment quality improvement in Aksu area[D]. Aral: Tarim University, 2022.
[4]	李怿炜. 新疆阿克苏市耕地主要养分时空富集特征及其影响因素研究[D]. 乌鲁木齐: 新疆农业大学, 2022.
	LI Yiwei. Study on Temporal and Spatial Enrichment Characteristics and Influencing Factors of Main Nutrients in Cultivated Land in Aksu City, Xinjiang[D]. Urumqi: Xinjiang Agricultural University, 2022.
[5]	张梦丽, 岳春芳, 李艺珍. 阿克苏地区成龄枣树气孔导度对气象因子的响应[J]. 节水灌溉, 2020, (7): 19-23.
	ZHANG Mengli, YUE Chunfang, LI Yizhen. Response of stomatal conductance of mature jujube to meteorological factors in Aksu Area[J]. Water Saving Irrigation, 2020, (7): 19-23.
[6]	李泽鸣, 魏占民, 刘虎, 等. 近37a新疆福海县ET₀变化趋势及影响分析[J]. 干旱区研究, 2015, 32(3): 573-578.
	LI Zeming, WEI Zhanmin, LIU Hu, et al. Trend of ET₀ change and its influence in Fuhai County of Xinjiang during recent 37 years[J]. Arid Zone Research, 2015, 32(3): 573-578.
[7]	李思思, 张飞云, 白磊, 等. 北疆地区生长季参考作物蒸散量的时空变化特征及其敏感性分析[J]. 中国农业气象, 2015, 36(6): 683-691.
	LI Sisi, ZHANG Feiyun, BAI Lei, et al. Spatiotemporal variation and sensitivity of reference crop evapotranspiration during growth season in northern Xinjiang[J]. Chinese Journal of Agrometeorology, 2015, 36(6): 683-691.
[8]	祁嘉郁, 巴特尔·巴克, 卡力比尔·买买提. 北疆春小麦不同生育阶段需水量变化的气候响应[J]. 麦类作物学报, 2021, 41(3):362-369.
	QI Jiayu, Bateer Bake, Kalibier Maimaiti. Climate Response of Water Demand Variation in Spring Wheat at Different Growth Stages in Northern Xinjiang[J]. Journal of Triticeae Crops, 2021, 41(3):362-369.
[9]	吴燕锋, 巴特尔·巴克, 罗那那, 等. 石河子地区冬小麦生育期需水量变化特征及其气候成因[J]. 水土保持通报, 2016, 36(1): 69-74.
	WU Yanfeng, Bateer Bake, LUO Nana, et al. Variations in water requirement of winter wheat at different growth stages and its climatic cause in Shihezi Region[J]. Bulletin of Soil and Water Conservation, 2016, 36(1): 69-74.
[10]	韦琦, 卫琦, 徐解刚, 等. 基于机器学习算法的ET₀预测研究[J]. 节水灌溉, 2022, (11): 9-17.
	WEI Qi, WEI Qi, XU Jiegang, et al. Research on ET₀ prediction based on machine learning algorithm[J]. Water Saving Irrigation, 2022, (11): 9-17.
[11]	夏兴生, 潘耀忠, 朱秀芳, 等. 农业分区框架下Hargreaves-Samani公式的逐月回归修正[J]. 农业机械学报, 2020, 51(3): 258-267.
	XIA Xingsheng, PAN Yaozhong, ZHU Xiufang, et al. Regression correction of hargreaves-samani equation by monthly under framework of China’s agricultural comprehensive zoning[J]. Transactions of the Chinese Society for Agricultural Machinery, 2020, 51(3): 258-267.
[12]	范文波, 吴普特, 韩志全, 等. 玛纳斯河流域ET₀影响因子分析及对Hargreaves法的修正[J]. 农业工程学报, 2012, 28(8): 19-24.
	FAN Wenbo, WU Pute, HAN Zhiquan, et al. Influencing factors analysis of reference crop evapotranspiration and modification of Hargreaves method ET₀in Manas River Basin[J]. Transactions of the Chinese Society of Agricultural Engineering, 2012, 28(8): 19-24.
[13]	赵璐, 梁川, 崔宁博, 等. 不同ET₀计算方法在川中丘陵地区的比较及改进[J]. 农业工程学报, 2012, 28(24): 92-98.
	ZHAO Lu, LIANG Chuan, CUI Ningbo, et al. Comparison and improvement of different calculation methods for ET₀ in hilly area of central Sichuan Basin[J]. Transactions of the Chinese Society of Agricultural Engineering, 2012, 28(24): 92-98.
[14]	郝林如, 郭向红, 雷涛, 等. 气象要素缺失条件下不同机器学习模型计算参考作物蒸散量比较[J]. 节水灌溉, 2022, (7): 102-108, 118.
	HAO Linru, GUO Xianghong, LEI Tao, et al. Comparison of reference crop evapotranspiration calculated by different machine learning models in absence of meteorological elements[J]. Water Saving Irrigation, 2022, (7): 102-108, 118.
[15]	王仰仁. 灌溉排水工程学[M]. 北京: 中国水利水电出版社, 2014.
	WANG Yangren. Irrigation and drainage engineering[M]. Beijing: China Water & Power Press, 2014.
[16]	Allen R G, Smith M, Perrier A, et al. An update for the definition of reference evapotranspiration[J]. ICID Bulletin, 1994, 43(2):1-34.
[17]	黄敬峰, 王秀珍, 蔡承侠. 新疆冬小麦物候与气候条件研究[J]. 中国农业气象, 2000, 21(1): 14-19.
	HUANG Jingfeng, WANG Xiuzhen, CAI Chengxia. Research on winter wheat phenology and climate in Xinjiang[J]. Chinese Journal of Agrometeorology, 2000, 21(1): 14-19.
[18]	王雪姣. 气候变化对新疆棉花物候、产量和品质的影响与适应措施[D]. 北京: 中国农业大学, 2015.
	WANG Xuejiao. Impact and Adaptation of Climate Change on Cotton Phenology, Yield and Fiber Quality in Xinjiang[D]. Beijing: China Agricultural University, 2015.
[19]	邱琳麟. 水资源约束下的塔里木河流域耕地适宜规模研究[D]. 上海: 华东师范大学, 2022.
	QIU Linlin. Appropriate scale study of cultivated land in the Tarim River Basin with water resource constraints[D]. Shanghai: East China Normal University, 2022.
[20]	赵永. 作物需水量计算方法比较与非充分灌溉预报研究[D]. 杨凌: 西北农林科技大学, 2004.
	ZHAO Yong. Comparing Different Methods of Calculating Crop Water Requirement & Study on Limited Irrigation Forecasting[D]. Yangling: Northwest A & F University, 2004.
[21]	王秀珍, 黄敬峰. 新疆大田玉米物候与气候研究[J]. 玉米科学, 1994, 2(2): 20-26.
	WANG Xiuzhen, HUANG Jingfeng. Study on phenology and climate of maize in Xinjiang field[J]. Maize Sciences, 1994, 2(2): 20-26.
[22]	马亚丽, 牛最荣, 张芮, 等. 疏勒河流域潜在蒸散发时空演变及驱动因素量化分析[J]. 水土保持研究, 2022, 29(5): 350-357.
	MA Yali, NIU Zuirong, ZHANG Rui, et al. Temporal and spatial evolution and driving factors of potential evapotranspiration in Shule River Basin[J]. Research of Soil and Water Conservation, 2022, 29(5): 350-357.
[23]	何军, 冯雅婷, 李亚龙, 等. 四种ET0计算方法在荆州地区的适用性分析[J]. 节水灌溉, 2020, (11): 16-19.
	HE Jun, FENG Yating, LI Yalong, et al. Analysis of applicability of four ET0 calculation methods in Jingzhou Area[J]. Water Saving Irrigation, 2020, (11): 16-19.
[24]	王君勤, 叶生进, 樊毅. 中国不同气候区参考作物蒸散量计算模型适用性评价[J]. 节水灌溉, 2022, (3): 82-91.
	WANG Junqin, YE Shengjin, FAN Yi. Applicability evaluation of reference crop evapotranspiration calculation models in different climatic regions of China[J]. Water Saving Irrigation, 2022, (3): 82-91.
[25]	高传昌, 朱明锋, 秦海霞. Hargraeves公式计算参考作物腾发量在新疆地区的适用性研究[J]. 灌溉排水学报, 2008,(3):60-62.
	GAO Chuanchang, ZHU Mingfeng, QING Haixia. Adaptability of Hargraeves Formulain Estimating Reference Evapotranspiration in Xinjiang Region[J]. Journal of Irrigation and Drainage, 2008, (3):60-62.
[26]	段峥嵘, 祖拜代·木依布拉, 夏建新. 新疆阿克苏地区潜在蒸散量时空演变及驱动因素[J]. 新疆大学学报(自然科学版), 2018, 35(4): 493-501, 512.
	DUAN Zhengrong, Zubaidai Muyibula, XIA Jianxin. Variation characteristics and influence factors of potential evapotranspiration in Aksu Region[J]. Journal of Xinjiang University (Natural Science Edition), 2018, 35(4): 493-501, 512.
[27]	张守红, 刘苏峡, 莫兴国, 等. 阿克苏河流域气候变化对潜在蒸散量影响分析[J]. 地理学报, 2010, 65(11): 1363-1370.
	ZHANG Shouhong, LIU Suxia, MO Xingguo, et al. Assessing the impact of climate change on reference evapotranspiration in Aksu River Basin[J]. Acta Geographica Sinica, 2010, 65(11): 1363-1370.
[28]	刘钰, 汪林, 倪广恒, 等. 中国主要作物灌溉需水量空间分布特征[J]. 农业工程学报, 2009, 25(12): 6-12.
	LIU Yu, WANG Lin, NI Guangheng, et al. Spatial distribution characteristics of irrigation water requirement for main crops in China[J]. Transactions of the Chinese Society of Agricultural Engineering, 2009, 25(12): 6-12.
	王志成, 方功焕, 张辉, 等. 阿克苏河灌区作物需水量对气候变化的敏感性分析[J]. 沙漠与绿洲气象, 2018, 12(3): 33-39.
	WANG Zhicheng, FANG Gonghuan, ZHANG Hui, et al. Sensitivity analysis of crop water requirement to meteorological factors in Aksu irrigation area[J]. Desert and Oasis Meteorology, 2018, 12(3): 33-39.
[29]	郑佳媛. 中国主要作物灌溉需水量的时空格局分析[D]. 鞍山: 辽宁科技大学, 2022.
	ZHENG Jiayuan. Analysis on Temporal and Spatial Pattern of Irrigation Water Demand of Main Crops in China[D]. Anshan: University of Science and Technology Liaoning, 2022.

作物 Crops	生育期 Fertility period	生育天数 Number of days of birth (d)	作物系数 Crop coefficients
冬小麦 Winter wheat	初始生长期	0~55	0.60
	冻融期	55~65	0.60~0.40
	越冬期	65~160	0.40
	快速发育期	160~220	0.40~1.17
	生育中期	221~255	1.17
	成熟期	255~270	1.17~0.4
棉花 Cotton	初始生长期	0~30	0.30
	快速发育期	30~70	0.30~1.15
	生育中期	70~120	1.15
	成熟期	120~160	1.15~0.7
春玉米 Spring corn	初始生长期	0~40	0.30
	快速发育期	40~100	0.30~1.15
	生育中期	100~125	1.15
	成熟期	125~145	1.15~0.30
夏玉米 Summer corn	初始生长期	0~20	0.65
	快速发育期	20~50	0.65~1.15
	生育中期	50~85	1.15
	成熟期	85~110	1.15~0.60

作物 Crops	生育期 Fertility period	生育天数 Number of days of birth (d)	作物系数 Crop coefficients
冬小麦 Winter wheat	初始生长期	0~55	0.60
	冻融期	55~65	0.60~0.40
	越冬期	65~160	0.40
	快速发育期	160~220	0.40~1.17
	生育中期	221~255	1.17
	成熟期	255~270	1.17~0.4
棉花 Cotton	初始生长期	0~30	0.30
	快速发育期	30~70	0.30~1.15
	生育中期	70~120	1.15
	成熟期	120~160	1.15~0.7
春玉米 Spring corn	初始生长期	0~40	0.30
	快速发育期	40~100	0.30~1.15
	生育中期	100~125	1.15
	成熟期	125~145	1.15~0.30
夏玉米 Summer corn	初始生长期	0~20	0.65
	快速发育期	20~50	0.65~1.15
	生育中期	50~85	1.15
	成熟期	85~110	1.15~0.60

作物 Crops	生育阶段 Growth stage	k=5%	k =25%	k =50%	k =75%	k =95%	均值 Average value
冬小麦 Winter wheat	播种-越冬	26.55	30.18	33.94	39.89	42.61	34.63
	越冬-返青	15.38	17.28	15.86	27.31	32.72	21.71
	返青-拔节	83.43	92.75	116.09	111.97	135.12	107.87
	拔节-抽穗	70.48	80.03	94.88	105.38	115.23	93.20
	抽穗-开花	36.94	39.89	41.03	40.69	35.91	38.89
	开花-灌浆	59.77	70.44	64.10	80.25	86.24	72.16
	灌浆-成熟	80.14	79.21	79.14	66.68	92.42	79.52
棉花 Cotton	播种-出苗	-0.70	17.06	8.04	18.19	18.19	12.16
	出苗-现蕾	68.81	61.82	88.96	46.64	93.82	72.01
	现蕾-开花	136.03	98.77	129.62	162.47	176.58	140.69
	开花-吐絮	217.21	323.77	316.75	332.48	350.01	308.04
春玉米 Spring corn	播种-出苗	2.67	18.64	18.66	16.15	19.57	15.14
	出苗-拔节	91.06	70.86	115.26	100.15	125.78	100.62
	拔节-抽穗	102.92	114.24	135.77	99.45	133.38	117.15
	抽穗-乳熟	87.08	107.82	136.97	148.47	173.64	130.79
	乳熟-成熟	20.44	37.55	3.84	48.26	39.01	29.82
夏玉米 Summer corn	播种-出苗	10.38	15.90	28.96	34.03	32.05	24.26
	出苗-拔节	90.10	106.83	141.02	128.26	154.51	124.14
	拔节-抽穗	49.44	49.77	52.50	61.15	62.28	55.03
	抽穗-乳熟	95.58	148.33	128.85	150.49	154.79	135.61
	乳熟-成熟	44.50	45.68	32.94	51.07	54.21	45.68

作物 Crops	生育阶段 Growth stage	k=5%	k =25%	k =50%	k =75%	k =95%	均值 Average value
冬小麦 Winter wheat	播种-越冬	26.55	30.18	33.94	39.89	42.61	34.63
	越冬-返青	15.38	17.28	15.86	27.31	32.72	21.71
	返青-拔节	83.43	92.75	116.09	111.97	135.12	107.87
	拔节-抽穗	70.48	80.03	94.88	105.38	115.23	93.20
	抽穗-开花	36.94	39.89	41.03	40.69	35.91	38.89
	开花-灌浆	59.77	70.44	64.10	80.25	86.24	72.16
	灌浆-成熟	80.14	79.21	79.14	66.68	92.42	79.52
棉花 Cotton	播种-出苗	-0.70	17.06	8.04	18.19	18.19	12.16
	出苗-现蕾	68.81	61.82	88.96	46.64	93.82	72.01
	现蕾-开花	136.03	98.77	129.62	162.47	176.58	140.69
	开花-吐絮	217.21	323.77	316.75	332.48	350.01	308.04
春玉米 Spring corn	播种-出苗	2.67	18.64	18.66	16.15	19.57	15.14
	出苗-拔节	91.06	70.86	115.26	100.15	125.78	100.62
	拔节-抽穗	102.92	114.24	135.77	99.45	133.38	117.15
	抽穗-乳熟	87.08	107.82	136.97	148.47	173.64	130.79
	乳熟-成熟	20.44	37.55	3.84	48.26	39.01	29.82
夏玉米 Summer corn	播种-出苗	10.38	15.90	28.96	34.03	32.05	24.26
	出苗-拔节	90.10	106.83	141.02	128.26	154.51	124.14
	拔节-抽穗	49.44	49.77	52.50	61.15	62.28	55.03
	抽穗-乳熟	95.58	148.33	128.85	150.49	154.79	135.61
	乳熟-成熟	44.50	45.68	32.94	51.07	54.21	45.68
