Effects of Different Irrigation Methods on Growth and Quality of Facility Cherry Tomatoes

doi:10.6048/j.issn.1001-4330.2021.11.016

Abstract

Abstract:

【Objective】 To screen out the best irrigation method for screening soilless cultivation of cherry tomatoes with a view to providing a theoretical basis for the precise management of water fertilizer for soilless cultivation of cherry tomatoes. 【Methods】 With high-sugar cherry tomatoes as the experimental material, coconut bran as the cultivation matrix, different irrigation methods were set under the condition of consistent environmental conditions, and the effects of high plant height, stem thickness, leaf area, fresh weight, dry weight, soluble sugar, soluble protein, photosynthesis rate of different irrigation methods on soilless soil-cultivated cherry tomato morphology, quality, yield and photosynthesis were studied. 【Results】 The effects of each treatment on the growth, yield and quality of cherry tomatoes were different, among which, the cherry tomato fruit index, fruit quality, photosynthesis parameters and yield of the irrigation method combining drip irrigation and tidal irrigation were better than the drip irrigation and tidal irrigation methods. 【Conclusion】 The irrigation method combining drip irrigation with tidal irrigation is most beneficial to the growth of soilless cherry tomatoes.

Key words: soilless cultivation; tidal irrigation; cherry tomatoes; growth quality

摘要：

【目的】筛选樱桃番茄无土栽培的最佳灌溉方式,为设施无土栽培樱桃番茄的水肥精准管理提供理论依据。【方法】以高糖樱桃番茄为材料,椰糠为栽培基质,在环境条件一致的情况下,设置不同的灌水方式,测定番茄幼苗的株高、茎粗、叶面积、鲜重、干重、可溶性糖、可溶性蛋白、光合速率等指标,研究不同灌溉方式对设施无土栽培樱桃番茄形态、品质、产量及光合作用的影响。【结果】各处理对樱桃番茄生长、产量及品质的影响不尽相同,其中,滴灌与潮汐式灌溉相结合的灌溉方式处理的樱桃番茄果形指数、果实品质、光合参数、产量最佳,其各指标要优于滴灌与潮汐式的灌溉方式。【结论】滴灌与潮汐式灌溉相结合的灌溉方式最有利于无土栽培的樱桃番茄生长。

关键词: 无土栽培, 潮汐式灌溉, 樱桃番茄, 生长品质

CLC Number:

S541.2

NIU Ning, GUO Jinfen, JING Bo, JIANG Xiyao, ZHAO Mingwei, DIAO Ming. Effects of Different Irrigation Methods on Growth and Quality of Facility Cherry Tomatoes[J]. Xinjiang Agricultural Sciences, 2021, 58(11): 2094-2102.

牛宁, 郭金芬, 景博, 蒋希瑶, 赵明伟, 刁明. 不同灌溉方式对设施樱桃番茄生长及品质的影响[J]. 新疆农业科学, 2021, 58(11): 2094-2102.

Figures/Tables 7

References 39

[1]	李式军. 珍稀名优蔬菜 [M]. 北京: 中国农业出版社, 1995: 168.
	Li Shijun. Rare and famous vegetables [M]. Beijing: China Agricultural Press, 1995: 168.
[2]	中国农业科学院蔬菜研究所. 中国蔬菜栽培学 [M]. 北京: 农业出版社, 1987: 624.
	Institute of Vegetables, Chinese Academy of Agricultural Sciences. China Olericulture [M]. Beijing: China Agriculture Press, 1987: 624.
[3]	岳冬, 刘娜, 朱为民, 等. 樱桃番茄与普通番茄部分品质指标及氨基酸组成比较[J]. 食品科学, 2015, 36(4):92-96.
	YUE Dong, LIU Na, ZHU Weimin, et al. Comparison of some quality indicators and amino acid composition of cherry tomatoes and ordinary tomatoes[J]. Food Science, 2015, 36(4):92-96.
[4]	Hesham, A R, Abdullah, I, Mahmoud, W A, et al. Response of cherry tomato (So lanumly copersicum var. cerasiforme) top runing systems and irrigation rates under greenhouse conditions[J]. Asian Journal of Crop Science, 2013, 5(3):275-285. DOI URL
[5]	蒋学杰, 于建清, 李爱科, 等. 鲁东南地区大棚长货架番茄品种比较试验[J]. 中国园艺文摘, 2010, (11):28.
	JIANG Xuejie, YU Jianqing, LI Aike, et al. Comparative test of tomato varieties with long shelf in greenhouses in southeastern Shandong[J]. Chinese Horticultural Abstracts, 2010,(11):28.
[6]	蒋学杰, 于建清, 李爱科. 鲁东南地区大棚长货架番茄品种比较试验 [J]. 中国园艺文摘, 2010, (11): 28,48.
	JIANG Xuejie, YU Jianqing, LI Aike. Comparative test of tomato varieties with long shelf in greenhouses in southeastern Shandong [J]. Chinese Horticultural Abstracts, 2010, (11): 28,48.
[7]	魏代芳, 李天亮, 张明坤, 等. 樱桃番茄盆栽技术[J]. 中国园艺文摘, 2010, (12):147-148.
	WEI Daifang, LI Tianliang, ZHANG Mingkun, et al. Cherry tomato potting technology[J]. Chinese Horticultural Abstracts, 2010,(12):147-148.
[8]	孙世海, 任志雨, 张卫华, 等. 固体基质无土栽培方式对樱桃番茄生长发育的影响[J]. 湖北农业科学, 2009, 48(2):351-353.
	SUN Shihai, REN Zhiyu, ZHANG Weihua, et al. Effects of solid substrate soilless cultivation on the growth and development of cherry tomatoes[J]. Hubei Agricultural Sciences, 2009, 48(2):351-353.
[9]	郝炎炎, 吕新. 膜下滴灌条件下加工番茄施肥推荐与决策支持系统的建立[J]. 土壤通报, 2007, 38(4):813-815.
	HAO Yanyan, LÜ Xin. Establishment of recommendation and decision support system for fertilization of processed tomatoes under drip irrigation under film[J]. Soil Bulletin, 2007, 38(4):813-815.
[10]	林春华, 黄亮华. 配方施肥对基质栽培樱桃番茄产量、品质和环境的影响[J]. 中国蔬菜, 2000, (1):11-13.
	LIN Chunhua, HUANG Lianghua. Effects of formula fertilization on yield, quality and environment of substrate-cultivated cherry tomatoes[J]. Chinese Vegetables, 2000,(1):11-13.
[11]	李英, 唐懋华, 赵俊杰, 等. 有机生态型无土栽培樱桃番茄新品种比较试验[J]. 江苏农业科学, 2011, 39(4):214-215.
	LI Ying, TANG Maohua, ZHAO Junjie, et al. Comparative experiment of organic ecological soilless cultivation of new cherry tomato varieties[J]. Jiangsu Agricultural Sciences, 2011, 39(4):214-215.
[12]	Elena Coyago-Cruz, Antonio J. Meléndez-Martínez, Alfonso Moriana, Ignacio F, Girón , María José Martín-Palomo, Alejandro Galindo, David Pérez-López, Arturo Torrecillas, Elena Beltrán-Sinchiguano, Mireia Corell. Yield response to regulated deficit irrigation of greenhouse cherry tomatoes[J]. Agricultural Water Management, 2019: 213.
[13]	高敏. 西安地区千禧樱桃番茄中棚栽培密度试验研究[D]. 杨凌:西北农林科技大学, 2010.
	GAO Min. Experimental study on the density of millennial cherry tomatoes in the shed in Xi'an area[D]. Yangling:Northwest A & F University, 2010.
[14]	钟泽, 杨云云, 肖梦, 等. 灌溉液不同pH值对椰糠种植番茄的影响[J]. 江苏农业科学, 2019, 47(2):112-114.
	ZHONG Ze, YANG Yunyun, XIAO Meng, et al. Effects of different pH values of irrigation liquid on tomato planting in coconut bran[J]. Jiangsu Agricultural Sciences, 2019, 47(2):112-114.
[15]	Liu, X J, Zhang, F S. Nitrogen fertilizer induced greenhouse gas emissions in China[J]. Current Opinion in Environmental Sustainability, 2011, 3(5):407-413. DOI URL
[16]	Guo, J H, Liu, X J, Zhang, Y, et al. Significant acidification in major Chinese croplands[J]. Science, 2010, 327(5968):1008. DOI PMID
[17]	刘富启. 樱桃番茄水肥一体化椰糠无土栽培技术[J]. 中国农技推广, 2019, 35(11):50-51.
	LIU Fuqi. Soilless cultivation technology of integrated fermented coconut bran with water and fertilizer for cherry tomatoes[J]. Chinese Agricultural Technology Extension, 2019, 35(11):50-51.
[18]	胡静, 杨惠玲, 甘小虎, 等. 意大利生菜潮汐式栽培生产试验[J]. 蔬菜, 2015, (3):13-15.
	HU Jing, YANG Huiling, GAN Xiaohu, et al. Experiment of tidal cultivation of lettuce in Italy[J]. Vegetables, 2015,(3):13-15.
[19]	董春娟, 张晓蕊, 尚庆茂. 蔬菜潮汐式育苗技术应用概况与研究进展[J]. 中国蔬菜, 2018,(3):16-26.
	DONG Chunjuan, ZHANG Xiaorui, SHANG Qingmao. General situation and research progress of tidal seedling raising technology for vegetables[J]. Chinese Vegetables, 2018,(3):16-26.
[20]	韩勇, 魏猷刚, 甘小虎, 等. 小青菜潮汐式灌溉栽培技术初探[J]. 金陵科技学院学报, 2013, (4):61-64.
	HAN Yong, WEI Yougang, GAN Xiaohu, et al. Preliminary study on tidal irrigation cultivation technology of small green vegetables[J]. Journal of Jinling Institute of Technology, 2013,(4):61-64.
[21]	张学军, 段静, 张月红, 等. 温室床式潮汐灌技术及其设计方法的研究[J]. 节水灌溉, 2012, (2):33-37.
	ZHANG Xuejun, DUAN Jing, ZHANG Yuehong, et al. Research on greenhouse bed tidal irrigation technology and its design method[J]. Water Saving Irrigation, 2012,(2):33-37.
[22]	柳红, 张玮, 严生德, 等. 黄瓜潮汐式灌溉育苗技术应用效果初报[J]. 青海农技推广, 2016,(3):16-18.
	LIU Hong, ZHANG Wei, YAN Shengde, et al. Preliminary report on application effect of cucumber tidal irrigation seedling raising technology[J]. Qinghai Agricultural Technology Extension, 2016,(3):16-18.
[23]	甘小虎, 何从亮, 胡静, 等. 辣椒潮汐式灌溉育苗技术应用效果初报[J]. 蔬菜, 2014, (6):14-16.
	GAN Xiaohu, HE Congliang, HU Jing, et al. Preliminary report on application effect of chili pepper tidal irrigation nursery technology[J]. Vegetables, 2014,(6):14-16.
[24]	张黎, 王勇. 盆栽八仙花潮汐灌溉栽培试验初探[J]. 北方园艺, 2011,(20):77-79.
	ZHANG Li, WANG Yong. Preliminary study on tidal irrigation cultivation experiment of potted hydrangea[J]. Northern Horticulture, 2011,(20):77-79.
[25]	高艳明, 刘宏久, 郑佳琦, 等. 黄瓜穴盘育苗潮汐灌溉技术研究[J]. 灌溉排水学报, 2016, 35(1):79-82.
	GAO Yanming, LIU Hongjiu, ZHENG Jiaqi, et al. Research on tidal irrigation technology of cucumber plug seedling cultivation[J]. Journal of Irrigation and Drainage, 2016, 35(1):79-82.
[26]	马俊峰. 日光温室番茄椰糠基质高效栽培技术[J]. 西北园艺(综合), 2019, (6):10-12.
	MA Junfeng. High-efficiency cultivation technology of tomato coconut bran substrate in sunlight greenhouse[J]. Northwest Horticulture (General), 2019,(6):10-12.
[27]	鲍士旦. 土壤农化分析 [M]. 北京: 中国农业出版社, 1999: 30- 34, 178-186.
	BAO Shidan. Soil agrochemical analysis [M]. Beijing: China Agriculture Press, 1999: 30- 34, 178-186.
[28]	高维钺, 任香爱, 李景华. 泥炭pH测法方法的研究[J]. 岩矿测试, 1989, 8(4):319-321.
	GAO Weiyue, REN Xiangai, LI Jinghua. Research on peat pH measurement method[J]. Rock and Mine Testing, 1989, 8(4):319-321.
[29]	黎秋君, 黎大荣, 王英辉, 等. 3种有机物料对土壤理化性质和重金属有效态的影响[J]. 水土保持学报, 2013, 27(6):182-185.
	LI Qiujun, LI Darong, WANG Yinghui, et al. Effects of three organic materials on soil physical and chemical properties and effective states of heavy metals[J]. Journal of Soil and Water Conservation, 2013, 27(6):182-185.
[30]	刘宏久, 高艳明, 李建设. 潮汐灌溉技术的研究进展[J]. 北方园艺, 2014, (10):174-176.
	LIU Hongjiu, GAO Yanming, LI Jianshe. Research progress of tidal irrigation technology[J]. Northern Horticulture, 2014,(10):174-176.
[31]	LAMES E, VAN LERSEL M. Ebb and flow production of pe-tunias and begonias affected and fertilizers with different phos-phorus content[J]. Hort Science, 2001, 36(2):282-285.
[32]	李梅玲. 潮汐灌溉小白菜穴盘栽培的水分管理研究[D]. 上海: 上海交通大学, 2014.
	LI Meiling. Study on the water management of small cabbage cultivation in tidal irrigation[D]. Shanghai: Shanghai Jiaotong University, 2014.
[33]	刘宏久, 高艳明, 沈富, 等. 番茄穴盘育苗潮汐灌溉技术研究[J]. 安徽农业大学学报, 2015, 42(4):549-554.
	LIU Hongjiu, GAO Yanming, SHEN Fu, et al. Study on tidal irrigation technology for tomato plug tray seedling cultivation[J]. Journal of Anhui Agricultural University, 2015, 42(4):549-554.
[34]	刘宏久, 郑佳琦, 高艳明, 等. 西葫芦穴盘育苗潮汐灌溉技术研究[J]. 湖北农业科学, 2015, 54(14):3413-3418.
	LIU Hongjiu, ZHENG Jiaqi, GAO Yanming, et al. Research on tidal irrigation technology of zucchini plug nursery[J]. Hubei Agricultural Sciences, 2015, 54(14):3413-3418.
[35]	李彪, 孟兆江, 申孝军, 等. 隔沟调亏灌溉对冬小麦-夏玉米光合特性和产量的影响[J]. 灌溉排水学报, 2018, 37(11):8-14.
	LI Biao, MENG Zhaojiang, SHEN Xiaojun, et al. Effects of Gully-Regulated Deficit Irrigation on Photosynthetic Characteristics and Yield of Winter Wheat and Summer Maize[J]. Journal of Irrigation and Drainage, 2018, 37(11):8-14.
[36]	于文颖, 纪瑞鹏, 冯锐, 等. 不同生育期玉米叶片光合特性及水分利用效率对水分胁迫的响应[J]. 生态学报, 2015, 35(9):2902-2909.
	YU Wenying, JI Ruipeng, FENG Rui, et al. Responses of maize leaf photosynthetic characteristics and water use efficiency to water stress at different growth stages[J]. Journal of Ecology, 2015, 35(9):2902-2909.
[37]	Chen, JL (Chen, Jinliang)1;Kang, SZ (Kang, Shaozhong)1;Du, TS (Du, Taisheng)1;Guo, P (Guo, Ping)1;Qiu, RJ (Qiu, Rangjian)1;Chen, RQ (Chen, Renqiang)1;Gu, F (Gu, Feng)1.. Modeling relations of tomato yield and fruit quality with water deficit at different growth stages under greenhouse condition[J]. Agricultural Water Management, 2014:131-148.
[38]	哈婷, 张向梅, 李建设, 等. 营养液供液量及供液频率对高糖度番茄生长、产量及品质的影响[J]. 西北农业学报, 2017, 26(10):1484-1491.
	HA Ting, ZHANG Xiangmei, LI Jianshe, et al. The effect of the amount and frequency of nutrient solution on the growth, yield and quality of high-sugar tomato[J]. Journal of Northwest Agriculture, 2017, 26(10):1484-1491.
[39]	季延海, 李炎艳, 武占会, 等. 灌溉量对限根栽培番茄生长和品质的影响[J]. 中国蔬菜, 2019,(10):19-25.
	JI Yanhai, LI Yanyan, WU Zhanhui, et al. Effect of Irrigation Quantity on Growth and Quality of Root-limited Cultivated Tomatoes[J]. China Vegetables, 2019,(10):19-25.

处理 Treatment	地上部分鲜重 Fresh weight On the ground (g)	地上部分干重 Dry weight On the ground (g)	地下部分鲜重 Fresh weight Under the ground (g)	地下部分干重 Dry weight under the ground (g)
1	(1 926.76±195.53)^a	(76.60±23.50)^ab	(213.50±26.40)^a	(8.64±1.16)^ab
2	(1 208.83±425.95)^b	(62.085±10.60)^b	(171.06±75.73)^a	(8.15±1.29)^b
3	(1 503.73±246.75)^b	(92.54±18.64)^a	(169.64±53.64)^a	(9.85±1.70)^a

处理 Treatment	地上部分鲜重 Fresh weight On the ground (g)	地上部分干重 Dry weight On the ground (g)	地下部分鲜重 Fresh weight Under the ground (g)	地下部分干重 Dry weight under the ground (g)
1	(1 926.76±195.53)^a	(76.60±23.50)^ab	(213.50±26.40)^a	(8.64±1.16)^ab
2	(1 208.83±425.95)^b	(62.085±10.60)^b	(171.06±75.73)^a	(8.15±1.29)^b
3	(1 503.73±246.75)^b	(92.54±18.64)^a	(169.64±53.64)^a	(9.85±1.70)^a

处理 Treatments	果横径 Diameter (mm)	果长 Length (mm)	果型指数 Shape index	果实壁厚 Wall thickness (mm)	果实硬度 Hardness (kg/cm²)
1	(23.44±2.34)^a	(36.64±5.15)^a	(1.56±0.14)^b	(2.33±0.79)^a	(10.80±1.96)^a
2	(22.44±1.98)^a	(35.90±2.55)^a	(1.61±0.20)^b	(2.13±0.47)^a	(11.68±1.67)^a
3	(19.74±3.35)^b	(37.16±5.28)^a	(1.92±0.32)^a	(2.31±0.44)^a	(10.91±2.13)^a

处理 Treatments	果横径 Diameter (mm)	果长 Length (mm)	果型指数 Shape index	果实壁厚 Wall thickness (mm)	果实硬度 Hardness (kg/cm²)
1	(23.44±2.34)^a	(36.64±5.15)^a	(1.56±0.14)^b	(2.33±0.79)^a	(10.80±1.96)^a
2	(22.44±1.98)^a	(35.90±2.55)^a	(1.61±0.20)^b	(2.13±0.47)^a	(11.68±1.67)^a
3	(19.74±3.35)^b	(37.16±5.28)^a	(1.92±0.32)^a	(2.31±0.44)^a	(10.91±2.13)^a

处理 Treatments	单果重 Single fruit weight (g)	单株产量 Yield per plant (kg)	折合产量 Yield (kg/mu)
1	(9.29±3.53)^b	(0.69±0.14)^b	(737.86±153.26)^b
2	(10.93±1.75)^b	(0.79±0.14)^b	(844.24±141.28)^b
3	(16.60±1.98)^a	(1.01±0.15)^a	(1 080.74±163.62)^a
