Effects of Biochar Input on Soil Organic Carbon and Maize Growth

doi:10.6048/j.issn.1001-4330.2022.04.005

Abstract

Abstract:

【Objective】 Based on its abundant micro-pore structure, specific surface area and aromatic functional group, Biochar can effectively increase the stability of soil organic carbon and improve soil quality.【Methods】 In this study, no exogenous carbon input was used as control (CK), the effects of different exogenous carbon input (straw 1%-Str1.0, straw 3%-Str3.0, straw10%-Str10.0, bio-carbon 0.8%-BC0.8, bio-carbon 2.4%-BC2.42, bio-carbon 8.0%-BC8.0) on soil water content, soil organic carbon content, maize chlorophyll content, net photosynthetic rate and yield were studied.【Results】 The results showed that compared with CK treatment, biochar input significantly increased the soil moisture content at the stage of leaf-pulling, jointing, flowering and ripening of maize by 0.38%-3.64%,1.57%-15.57%, 0.37%-3.88%, respectively (P<0.05) ; After biochar input, soil organic carbon increased by 72.21%-99.45% in different growth stages of maize, while straw input increased soil organic carbon by 30.78%-41.38% in different growth stages of maize and the effects of biochar on the chlorophyll content (SPAD) of maize were increased by 13.33% and 0.07% at flowering stage and maturity stage, respectively.Compared with CK treatment, the net photosynthetic rate of maize at different growth stages increased by 15.99%-29.11% under biochar input, and the biggest increase was at flowering stage.Compared with CK treatment, corn yield was increased by 15.71% and 18.80% under the condition of biochar (BC0.8 and BC2.4).【Conclusion】 The biochar BC0.8 and Str10.0 could effectively fertilize soil, promote corn growth and increase yield.

Key words: biomass carbon; straw; soil organic matter; corn; yield

摘要：

【目的】研究生物炭输入对土壤有机碳和玉米生长的影响。【方法】以无外源碳输入处理为对照(CK),研究不同外源碳(秸秆及其生物炭)等碳量输入条件下(秸秆1%-Str1.0、秸秆3%-Str3.0、秸秆10%-Str10.0;生物炭0.8%-BC0.8、生物炭2.4%-BC2.4、生物炭8.0%-BC8.0),对土壤含水率、土壤有机碳含量、玉米叶绿素度、净光合速率及产量的影响规律。【结果】较CK处理,输入生物炭显著增加了玉米抽叶期、拔节期、开花期、成熟期的土壤含水率,增幅分别为0.38%3.64%、1.57%15.57%、0.37%3.88%,差异性显著(P<0.05);生物炭输入后,玉米不同生育期土壤有机碳含量增加了72.21%99.45%,而秸秆碳输入,则使得玉米不同生育期土壤有机碳含量分别增加了30.78%41.38%;生物炭输入对玉米叶绿素度(SPAD)在开花期和成熟期分别较CK处理提高13.33%、0.07%。玉米不同生育期净光合速率相较CK处理提高了15.99%29.11%,且以开花期的增幅最大。生物炭少量和适量输入(BC0.8和BC2.4)条件下,玉米产量较CK处理分别提高15.71%和18.80%。【结论】向土壤中输入生物炭BC0.8和Str10.0可以有效的培肥土壤,促进玉米生长和提高产量。

关键词: 生物炭, 秸秆, 土壤有机碳, 玉米, 产量

CLC Number:

S156.2S156.92

WANG Zhenguo, MA Yuanyuan, WANG Xina, LIU Shaoquan, GU Chaofeng, JI Qiang. Effects of Biochar Input on Soil Organic Carbon and Maize Growth[J]. Xinjiang Agricultural Sciences, 2022, 59(4): 818-826.

汪振国, 马媛媛, 王西娜, 刘少泉, 古超峰, 姬强. 生物炭输入对土壤有机碳和玉米生长的影响[J]. 新疆农业科学, 2022, 59(4): 818-826.

Figures/Tables 7

References 34

[1]	高利华, 屈忠义, 丁艳宏, 等. 秸秆不同还田方式对土壤理化性质及玉米产量的影响研究[J]. 中国农村水利水电, 2016,(9):28-34.
	GAO Lihua, QU Zhongyi, DING Yanhong, et al. Study on Impacts of Returning Straw in Different Ways on Soil Physical & Chemical Characters and Yield of Maize[J]. China Rural Water Conservancy and Hydropower, 2016,(9):28-34.
[2]	王月宁, 冯朋博, 李荣, 等. 不同秸秆还田方式对宁夏扬黄灌区土壤性质及玉米生长的影响[J]. 西南农业学报, 2019, 32(11):2607-2614.
	WANG Yuening, FENG Pengbo, LI Rong, et al. Effects of Different Straw Returning Methods on Soil Properties and Corn Growth in Yanghuang Irrigation Area of Ningxia[J]. Southwest Agricultural Journal 2019, 32(11):2607-2614.
[3]	焦炳忠. 宁夏扬黄灌区不同灌溉模式对玉米生长及土壤水分时空分布的影响[D]. 银川:宁夏大学, 2017.
	JIAO Bingzhong. The effects of different irrigation patterens on maize grouth and temporal and spatial distribution of soil moisture in the arid irrigable area of Ningxia[D]. Yinchuan: Ningxia University, 2017.
[4]	鲁向晖, 高鹏, 王飞, 等. 宁夏南部山区秸秆覆盖对春玉米水分利用及产量的影响[J]. 土壤通报, 2008,(6):1248-1251.
	LU Xianghui, GAO Peng, WANG Fei, et al. Effect of Straw Mulch on Yield and Water Utilization of Spring Maize in the South Mountainous Area of Ningxia[J]. Soil Bulletin, 2008,(6):1248-1251.
[5]	潘剑玲, 代万安, 尚占环, 等. 秸秆还田对土壤有机质和氮素有效性影响及机制研究进展[J]. 中国生态农业学, 2013, 21(5):526-530.
	PAN Jianling, DAI Wanan, SHANG Zhanhuan, et al. Review of research progress on the influence and mechanism of field straw residue incorporation soil organic matter and nitrogen availability[J]. Chinese Journal of Eco-Agriculture, 2013, 21(5):526-530. DOI URL
[6]	毛明翠, 刘畅, 曹静, 等. 生物质炭对果园土壤团聚体分布及保水性影响[J]. 资源节约与环保, 2018,(11):13-15.
	MAO Mingcui, LIU Chang, CAO Jing, et al. Effect of Biochar on the Distribution and Water Retention of Soil Aggregate in Orchard[J]. Resource Conservation and Environmental Protection, 2018,(11):13-15.
[7]	安艳, 姬强, 赵世翔, 等. 生物质炭对果园土壤团聚体分布及保水性的影响[J]. 环境科学, 2016, 37(1):293-300.
	AN Yan, JI Qiang, ZHAO Shixiang, et al. Effect of Biochar Application on Soil AggregatesDistribution and Moisture Retention in Orchard Soil[J]. Environmental Science, 2016, 37(1):293-300.
[8]	周际海, 陈晏敏, 袁颖红, 等. 秸秆与生物质炭施用对土壤温室气体排放的影响差异[J]. 水土保持学报, 2019, 33(4):248-254.
	ZHOU Jihai, CHEN Yanmin, YUAN Yinghong, et al. Effects of Biochar and Wheat Straw Returning on Soil Greenhouse Gases Emission.[J]. Journal of Soil and Water Conservation, 2019, 33(4):248-254.
[9]	Naeem M A, Khalid M, Aon M, et al. Combinedapplication of biochar with compost and fertilizer improvessoil propertiesand grain yield of maize[J]. Journal of Plant Nutrition, 2018, 41(1):112-122. DOI URL
[10]	白小艳, 窦森. 施玉米秸秆生物质炭对土壤腐殖质组成和结构特征的影响[J]. 吉林农业大学学报, 2019, 41(3):330-335.
	BAI Xiaoyan, DOU Sen. Effects of Applying Corn Straw Biochar on Composition andStructural Characteristics of Soil Humus[J]. Journal of Jilin Agricultural University, 2019, 41(3):330-335.
[11]	邵慧芸. 有机物料施用对土壤有机碳组分和团聚体的影响[D]. 杨凌:西北农林科技大学, 2019.
	SHAO Huiyun. Effects of application of organic materials on soil organic carbon components and aggregates[D]. Yangling: Northwest A& F University, 2019.
[12]	徐国鑫. 不同施肥处理对紫色土旱坡地氮磷流失及作物效应的影响[D]. 重庆:西南大学, 2019.
	XU Guoxin. Effects of Different Fertilization Treatments on Nitrogen and Phosphorus Losses in Purple Soil Dry Slope Land and Crop Effect[D]. Chongqing: Southwest University, 2019.
[13]	姬强, 马媛媛, 刘永刚, 等. 秸秆生物质炭对土壤结构体与活性碳分布转化酶动力学参数及小麦生长的影响[J]. 生态学报, 2019, 39(12):4366-4375.
	JI Qiang, MA Yuanyuan, LIU Yonggang, et al. Effects of Straw Biochar on Soil Structure and Active Carbon Distribution Invertase Kinetic Parameters and Wheat Growth[J]. Ecologica Sinica, 2019, 39(12):4366-4375.
[14]	纪磊, 岳鑫, 陈磊, 等. 生物质炭和秸秆对土壤团聚体腐殖物质组成的影响[J]. 山东农业科学, 2019, 51(1):91-97.
	JI Lei, YUE Xin, CHEN Lei, et al. The effect of biomass charcoal and straw on the humus composition of soil aggregates[J]. Shandong Agricultural Sciences, 2019, 51(1):91-97.
[15]	孟祥天, 蒋瑀霁, 王晓玥, 等. 生物质炭和秸秆长期还田对红壤团聚体和有机碳的影响[J]. 土壤, 2018, 50(2):326-332.
	MENG Xiangtian, JIANG Yuji, WANG Xiaoyue, et al. Effects of long-term return of biomass charcoal and straw into the field on red soil aggregates and organic carbon Distribution[J]. Soils, 2018, 50(2):326-332.
[16]	尹艳. 不同培养条件下生物质炭添加对土壤有机碳矿化的影响研究[D]. 福州:福建师范大学, 2018.
	YIN Yan. Study on the Effect of Biochar Addition on Soil Organic Carbon Mineralization under Different Culture Conditions[D]. Fuzhou: Fujian Normal University, 2018.
[17]	申磊. 生物质炭及其老化对茶园土壤吸附固定镉的影响研究[D]. 曲阜: 曲阜师范大学, 2018.
	SHEN Lei. Study on the Effect of Biomass Charcoal and Its Aging on the Adsorption and Fixation of Cadmium in Tea Garden Soil[D]. Qufu: Qufu Normal University, 2018.
[18]	姬强. 不同耕作措施和外源碳输入对土壤结构和有机碳库的影响[D]. 杨凌:西北农林科技大学, 2016.
	JI Qiang. Effects of different farming measures and external carbon input on soil structure and organic carbon pool[D]. Yangling:Northwest A & F University, 2016.
[19]	XU X R, CHENG K, WU H, et al. Greenhouse gasmitigation potential in crop production with biochar soil amendment—a carbon footprint assessment for cross-sitefield experiments from China[J]. Gcb Bioenergy, 2019, 11(4):592-605. DOI URL
[20]	Gong X M, Huang D L, Liu yg, et al. Biocharfacilitated the phytoremediation of cadmium contaminatedsediments Metal behavior,plant toxicity,and microbialactivity[J]. Sci Total Environ, 2019,(6):1126-1133.
[21]	张俊叶, 刘晓东, 王林, 等. 生物质炭的土壤效应研究综述[J]. 中国农学通报, 2020, 36(9):46-50.
	ZHANG Junye, LIU Xiaodong, WANG Lin, et al. Summary of the Research on the Soil Effects of Biochar[J]. Chinese Agricultural Science Bulletin, 2020, 36(9):46-50.
[22]	李世忠, 冯海东, 解倩, 等. 宁夏引黄灌区土壤物理性状对玉米秸秆还田的响应[J]. 农业科学研究, 2017, 8(2):19-22.
	LI Shizhong, FENG Haidong, XIE Qian, et al. Responses of Soil Physical Properties to Corn Stalks Returning to Field in the Yellow River Irrigation Area of Ningxia[J]. Agricultural Science Research, 2017, 8(2):19-22.
[23]	李晓, 张吉旺, 李恋卿, 等. 施用生物质炭对黄淮海地区玉米生长和土壤性质的影响[J]. 土壤, 2014, 46(2):269-274.
	LI Xiao, ZHANG Jiwang, LI Lianqing, et al. Effect of the application of biochar on soil properties and maize growing areas of the North China[J]. Soils, 2014, 46(2):269-274.
[24]	刘岩. 水稻秸秆与其制备的生物质炭输入对土壤有机碳矿化的影响[D]. 福州:福建师范大学, 2017.
	LIU Yan. The effect of rice straw and biochar input on soil organic carbon mineralization[D]. Fuzhou: Fujian Normal University, 2017.
[25]	黄婷. 生物质炭对滴灌棉花氮磷养分吸收的影响机制[D]. 石河子:石河子大学, 2017.
	HUANG Ting. The Effect Mechanism of Biochar on the Absorption of Nitrogen and Phosphorus in Drip Irrigation Cotton[D]. Shihezi: Shihezi University, 2017.
[26]	南学军. N肥配施生物质炭和秸秆还田对土壤和小麦氮磷含量及其N:P的影响[D]. 兰州:甘肃农业大学, 2017.
	NAN Xuejun. Effects of combined application of N fertilizer with biomass charcoal and straw returning on soil and wheat nitrogen and phosphorus content and its N:P[D]. Lanzhou: Gansu Agricultural University, 2017.
[27]	陆文龙. 秸秆改良农田土壤中氮磷形态分布及玉米生长发育特征[D]. 长春:吉林大学, 2016.
	LU Wenlong. Distribution of Nitrogen and Phosphorus Forms in Farmland Soil Improved by Straw and Growth and Development Characteristics of Corn[D]. Changchun: Jilin University, 2016.
[28]	张婷. 生物质炭和秸秆配合施用对土壤有机碳氮转化的影响[D]. 杨凌:西北农林科技大学, 2016.
	ZHANG Ting. Effect of combined application of biomass charcoal and straw on the transformation of soil organic carbon and nitrogen[D]. Yangling: Northwest A & F University, 2016.
[29]	崔全红. 不同有机物料投入对土壤有机碳和养分含量的影响[D]. 杨凌:西北农林科技大学, 2016.
	CUI Quanhong. Effects of Different Organic Material Inputs on Soil Organic Carbon and Nutrient Content[D]. Yangling: Northwest A & F University, 2016.
[30]	张晗芝, 黄云, 刘钢, 等. 生物炭对玉米苗期生长及养分吸收及土壤化学性状的影响[J]. 生态环境学报, 2010, 19(11):2713-2717.
	ZHANG Hanzhi, HUANG Yun, LIU Gang, et al. Effect of Biochar on Growth and Nutrient Absorption of Maize Seedling and Soil Chemical Properties[J]. Ecology and Environmental Sciences, 2010, 19(11):2713-2717.
[31]	Asai H, Samson B K, Stephan H M, et al. Biochar amendment techniques for upland rice production in Northern Laos: 1.Soil physicalproperties, leaf SPAD and grain yield[J]. Field Crops Research, 2009, 111:81-84. DOI URL
[32]	谢祖彬, 刘琦. 生物质炭的固碳减排与合理施用[J]. 农业环境科学学报, 2020, 39(4):901-907.
	XIE Zubin, LIU Qi. Carbon sequestration, emission reduction and rational use of biomass charcoal[J]. Journal of Agricultural Environmental Sciences, 2020, 39(4):901-907.
[33]	凌宏伟, 李小英. 生物质炭对大田作物生长的影响研究进展[J]. 广东农业科学, 2018, 45(6):56-62.
	LING Hongwei, LI Xiaoying. Research Progress on the Effects of Biochar on the Growth of Field Crops[J]. Guangdong Agricultural Sciences, 2018, 45(6):56-62.
[34]	赵熙君, 冷雪梅, 张旭辉, 等. 生物质炭施用对重金属污染水稻土有机碳矿化的影响[J]. 南京农业大学学报, 2020, 43(3):468-476.
	ZHAO Xijun, LENG Xuemei, ZHANG Xuhui, et al. Effect of Biochar Application on Organic Carbon Mineralization of Heavy Metal Polluted Paddy Soil[J]. Journal of Nanjing Agricultural University, 2020, 43(3):468-476.

处理 Treatments	抽叶期 Leaf development	拔节期 Stem elongation	开花期 Flowering	成熟期 Ripening
BC0.8	13.99±0.94 ^deC	12.27±0.96^dD	15.03±0.28^bcB	19.61±0.59^cdA
BC2.4	14.46±1.34^cdB	12.65±0.84^dD	13.47±1.14^cdC	22.70±0.54^bA
BC8.0	17.24±1.24^bC	25.81±2.58^bA	14.78±1.75^cdD	23.12±0.91^bcB
Str1.0	15.06±0.69 ^bcC	11.88±1.14^deD	15.24±0.47^bB	22.33±1.61^bcA
Str3.0	15.76±0.62^bcB	14.54±2.32^cC	13.38±0.15^eD	19.35±0.48^cdA
Str10.0	29.87±1.22^aB	31.36±0.74^aC	19.74±0.59 ^aD	34.90±0.76^aA
CK	13.61±0.36^deC	10.70±1.41^efD	15.28±0.22^bcB	19.24±0.42^deA

处理 Treatments	抽叶期 Leaf development	拔节期 Stem elongation	开花期 Flowering	成熟期 Ripening
BC0.8	13.99±0.94 ^deC	12.27±0.96^dD	15.03±0.28^bcB	19.61±0.59^cdA
BC2.4	14.46±1.34^cdB	12.65±0.84^dD	13.47±1.14^cdC	22.70±0.54^bA
BC8.0	17.24±1.24^bC	25.81±2.58^bA	14.78±1.75^cdD	23.12±0.91^bcB
Str1.0	15.06±0.69 ^bcC	11.88±1.14^deD	15.24±0.47^bB	22.33±1.61^bcA
Str3.0	15.76±0.62^bcB	14.54±2.32^cC	13.38±0.15^eD	19.35±0.48^cdA
Str10.0	29.87±1.22^aB	31.36±0.74^aC	19.74±0.59 ^aD	34.90±0.76^aA
CK	13.61±0.36^deC	10.70±1.41^efD	15.28±0.22^bcB	19.24±0.42^deA

处理 Treatments	抽叶期 Leaf development	开花期 Flowering	成熟期 Fuit development stage
BC0.8	42.63±2.34^cA	35.47±2.63^efB	26.03±1.59^bcC
BC2.4	46.23±1.81^aA	36.73±2.40^cdB	25.70±1.65^cdC
BC8.0	44.20±1.04^bA	33.67±1.70^aB	25.37±1.01^eC
Str1.0	44.17±2.33^bc	35.57±1.40^de	27.23±1.67^b
Str3.0	44.27±2.66^bA	36.10±1.97^dB	24.20±1.59^efC
Str10.0	26.40±1.66^eC	45.80±1.91^aA	41.13±2.68^aAB
CK	44.23±2.19^cdA	38.87±0.32^bB	25.50±1.65^deC

处理 Treatments	抽叶期 Leaf development	开花期 Flowering	成熟期 Fuit development stage
BC0.8	42.63±2.34^cA	35.47±2.63^efB	26.03±1.59^bcC
BC2.4	46.23±1.81^aA	36.73±2.40^cdB	25.70±1.65^cdC
BC8.0	44.20±1.04^bA	33.67±1.70^aB	25.37±1.01^eC
Str1.0	44.17±2.33^bc	35.57±1.40^de	27.23±1.67^b
Str3.0	44.27±2.66^bA	36.10±1.97^dB	24.20±1.59^efC
Str10.0	26.40±1.66^eC	45.80±1.91^aA	41.13±2.68^aAB
CK	44.23±2.19^cdA	38.87±0.32^bB	25.50±1.65^deC

处理 Treatments	抽叶期 Leaf development	开花期 Flowering	成熟期 Fuit development stage
BC0.8	12.43±1.28^bcC	32.65±0.95^bcA	27.40±0.56^cdB
BC2.4	14.60±0.56^aC	36.40±0.73^aA	31.73±0.62^bB
BC8.0	14.03±0.28^abC	34.68±0.48^bA	33.83±0.25^aB
Str1.0	12.23±0.38^cdC	29.28±0.87^cdB	30.25±0.37^bcA
Str3.0	10.90±0.16^fC	26.75±0.49^deB	29.38±0.64^bcA
Str10.0	11.33±0.42^efC	17.93±0.59^gB	21.90±0.68^fA
CK	11.80±0.14^deC	22.53±0.64^fB	24.00±0.66^deA
